Performance |
---|
Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8, Windows Vista |
Linux operating systems supported | Kernel 2.6.33, Kernel 3.12, Kernel 3.17, Kernel 3.3, Kernel 4.6.4, Linux Kernel 5.10, Linux Kernel 5.11, Linux Kernel 5.12, Linux Kernel 5.13, Linux Kernel 5.14, Linux Kernel 5.15, Linux Kernel 5.8, Linux Kernel 5.9 |
Interface | PCI Express 4.0 |
Component for | Game console |
SSD capacity | 1 TB |
Read speed | 5000 MB/s |
Write speed | 3500 MB/s |
NVMe | Yes |
PCI Express interface data lanes | x4 |
Random read (4KB) | 480000 IOPS |
Random write (4KB) | 500000 IOPS |
S.M.A.R.T. support | Yes |
Hardware encryption | No |
Mean time between failures (MTBF) | 1500000 h |
TBW rating | 250 |
Design |
---|
SSD form factor | M.2 |
System requirements |
---|
Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8, Windows Vista |
Linux operating systems supported | Kernel 2.6.33, Kernel 3.12, Kernel 3.17, Kernel 3.3, Kernel 4.6.4, Linux Kernel 5.10, Linux Kernel 5.11, Linux Kernel 5.12, Linux Kernel 5.13, Linux Kernel 5.14, Linux Kernel 5.15, Linux Kernel 5.8, Linux Kernel 5.9 |
Features |
---|
Interface | PCI Express 4.0 |
Component for | Game console |
SSD capacity | 1 TB |
Read speed | 5000 MB/s |
Write speed | 3500 MB/s |
NVMe | Yes |
PCI Express interface data lanes | x4 |
Random read (4KB) | 480000 IOPS |
Random write (4KB) | 500000 IOPS |
S.M.A.R.T. support | Yes |
Hardware encryption | No |
Mean time between failures (MTBF) | 1500000 h |
TBW rating | 250 |
Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8, Windows Vista |
Linux operating systems supported | Kernel 2.6.33, Kernel 3.12, Kernel 3.17, Kernel 3.3, Kernel 4.6.4, Linux Kernel 5.10, Linux Kernel 5.11, Linux Kernel 5.12, Linux Kernel 5.13, Linux Kernel 5.14, Linux Kernel 5.15, Linux Kernel 5.8, Linux Kernel 5.9 |
SSD form factor | M.2 |
M.2 SSD size | 2230 (22 x 30 mm) |
Power |
---|
Operating voltage | 3.3 V |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 70 °C |
Storage temperature (T-T) | -40 - 85 °C |
Operating shock | 1500 G |
Operating vibration | 20 G |
Technical details |
---|
Interface | PCI Express 4.0 |
Operating temperature (T-T) | 0 - 70 °C |
Storage temperature (T-T) | -40 - 85 °C |
Operating shock | 1500 G |
Operating vibration | 20 G |
SSD form factor | M.2 |
Sustainability compliance | Yes |
Sustainability certificates | CE, Federal Communications Commission (FCC), RoHS, UKCA, WEEE |
Software |
---|
Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8, Windows Vista |
Linux operating systems supported | Kernel 2.6.33, Kernel 3.12, Kernel 3.17, Kernel 3.3, Kernel 4.6.4, Linux Kernel 5.10, Linux Kernel 5.11, Linux Kernel 5.12, Linux Kernel 5.13, Linux Kernel 5.14, Linux Kernel 5.15, Linux Kernel 5.8, Linux Kernel 5.9 |
Weight & dimensions |
---|
Width | 22 mm |
Depth | 30 mm |
Height | 3.7 mm |
Weight | 3 g |
