All stock codes associated to this product
EAP783, NWTL-EAP783, NWTLEAP783, 0840030710070
| Performance |
|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Flow control support | Yes |
| Automatic channel selection | Yes |
| Maximum data transfer rate | 19000 Mbit/s |
| Ethernet LAN data rates | 10000 Mbit/s |
| Frequency band | 2.4 - 6 GHz |
| Number of users | 760 user(s) |
| VLAN support | Yes |
| Reset button | Yes |
| Rate limiting | Yes |
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Band steering | Yes |
| Airtime Fairness (ATF) | Yes |
| Features |
|---|
| 6 GHz | Yes |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Flow control support | Yes |
| Automatic channel selection | Yes |
| Maximum data transfer rate | 19000 Mbit/s |
| Ethernet LAN data rates | 10000 Mbit/s |
| Frequency band | 2.4 - 6 GHz |
| Number of users | 760 user(s) |
| VLAN support | Yes |
| Rate limiting | Yes |
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n |
| Automatic channel scanning | Yes |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Band steering | Yes |
| Airtime Fairness (ATF) | Yes |
| Maximum data transfer rate (2.4 GHz) | 1376 Mbit/s |
| Maximum data transfer rate (5 GHz) | 5760 Mbit/s |
| Maximum data transfer rate (6 GHz) | 11520 Mbit/s |
| BeamForming | Yes |
| Security |
|---|
| Security algorithms | WPA, WPA2, WPA3 |
| Access Control List (ACL) | Yes |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 2 |
| DC-in jack | Yes |
| Power |
|---|
| Power over Ethernet (PoE) | Yes |
| DC voltage range | 12 V |
| Design |
|---|
| Placement | Ceiling, Wall |
| Reset button | Yes |
| LED indicators | Yes |
| Product colour | White |
| Antenna |
|---|
| Antenna type | Internal |
| Software |
|---|
| Automatic channel scanning | Yes |
| Access Control List (ACL) | Yes |
| Weight & dimensions |
|---|
| Width | 280 mm |
| Depth | 280 mm |
| Height | 46.5 mm |
| Packaging data |
|---|
| Quick start guide | Yes |
| Mounting kit | Yes |
| Package type | Box |
| Number of products included | 1 pc(s) |
| Packaging content |
|---|
| Quick start guide | Yes |
| Mounting kit | Yes |
| Number of products included | 1 pc(s) |
| Package type | Box |
| Operational conditions |
|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
Multi-Link Operation (MLO)
Enables devices to simultaneously send and receive data across different frequency bands and channels.
Two 10G PoE++ Ports
Boosts overall throughput and offers flexible deployment with two 10 Gbps PoE++ ports.
Auto Channel Selection and Power Adjustment
Boost WiFi performance and minimize interference for your network.
Intelligent Power Management
Offers more reliable network operation for your business.
Centralized Cloud Management
Manage the whole network locally or from the cloud.
Omada Mesh Technology
More flexible and convenient wireless deployment.â–³
PoE++ Power
Supports both 12V DC and 802.3bt PoE++ for flexible installations.
