Ports & interfaces |
---|
Internal | Yes |
Connectivity technology | Wired |
Host interface | PCI Express |
Interface | Ethernet |
Ethernet LAN (RJ-45) ports | 4 |
Bandwidth |
---|
Maximum data transfer rate | 2000 Mbit/s |
Full duplex | Yes |
Network |
---|
Chipset | Realtek RTL8111G |
Maximum data transfer rate | 2000 Mbit/s |
Ethernet LAN | Yes |
Ethernet LAN data rates | 10,1000,100 Mbit/s |
Cabling technology | 10/100/1000BaseT(X) |
Networking standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
Wake-on-LAN ready | Yes |
Auto MDIX IEEE | No |
Jumbo frames support | Yes |
Full duplex | Yes |
Flow control support | Yes |
Design |
---|
Internal | Yes |
Chipset | Realtek RTL8111G |
LED indicators | Activity, Link |
System requirements |
---|
Server operating systems supported | Windows Server 2003, Windows Server 2012, Windows Server 2016, Windows Server 2019 |
Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 |
Linux operating systems supported | Yes |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 55 °C |
Storage temperature (T-T) | -40 - 75 °C |
Operating relative humidity (H-H) | 5 - 95% |
Sustainability |
---|
Sustainability certificates | CE, RoHS |
Weight & dimensions |
---|
Width | 120 mm |
Depth | 138 mm |
Height | 18 mm |
Weight | 95 g |
Package width | 209 mm |
Package depth | 145 mm |
Package height | 40 mm |
Package weight | 184 g |
Packaging data |
---|
Package width | 209 mm |
Package depth | 145 mm |
Package height | 40 mm |
Package weight | 184 g |
Performance |
---|
Server operating systems supported | Windows Server 2003, Windows Server 2012, Windows Server 2016, Windows Server 2019 |
Wake-on-LAN ready | Yes |
Auto MDIX IEEE | No |
Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 |
Linux operating systems supported | Yes |
Technical details |
---|
Harmonized System (HS) code | 85176990 |
Sustainability certificates | CE, RoHS |
Compliance certificates | CE, RoHS |
Case colour | Yellow |
Other features |
---|
Chipset | Realtek RTL8111G |
Case colour | Yellow |
Flow control support | Yes |
Harmonized System (HS) code | 85176990 |
Logistics data |
---|
Master (outer) case width | 446 mm |
Master (outer) case length | 521 mm |
Master (outer) case height | 344 mm |
Products per master (outer) case | 50 pc(s) |
Harmonized System (HS) code | 85176990 |
