Management features |
---|
Reset button | Yes |
Power |
---|
Power connector | AC-in jack |
Power consumption (max) | 240 W |
Power supply included | Yes |
AC input voltage | 110 - 240 V |
AC input frequency | 50/60 Hz |
Number of power supply units | 1 |
Input current | 4.4 A |
DC input voltage | 48 V |
Power source | AC |
Ports & interfaces |
---|
Basic switching RJ-45 Ethernet ports quantity | 9 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Power connector | AC-in jack |
Network |
---|
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Data transmission |
---|
Switching capacity | 18 Gbit/s |
Forwarding rate | 26.78 Mpps |
Throughput | 9 Gbit/s |
Design |
---|
Reset button | Yes |
Rack mounting | Yes |
Form factor | 1U |
LED indicators | Yes |
Housing material | Steel |
Technical details |
---|
Sustainability compliance | Yes |
Sustainability certificates | CE, Federal Communications Commission (FCC) |
Power over Ethernet (PoE) |
---|
Power over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) ports quantity | 4 |
Power over Ethernet plus (PoE+) ports quantity | 4 |
Total Power over Ethernet (PoE) budget | 120 W |
Power over Ethernet (PoE) voltage | 57 V |
Power over Ethernet 4PPoE (PoE++) ports quantity | 4 |
Operational conditions |
---|
Operating temperature (T-T) | -5 - 40 °C |
Operating relative humidity (H-H) | 5 - 95% |
Weight & dimensions |
---|
Width | 442 mm |
Depth | 480 mm |
Height | 44 mm |
Weight | 9 kg |
Sustainability |
---|
Sustainability compliance | Yes |
Sustainability certificates | CE, Federal Communications Commission (FCC) |
Other features |
---|
Ethernet LAN data rates | 10,100,1000 Mbit/s |
