LAN Ports | 1 x 10Gbps for WAN/LAN 1 x 2.5Gbps for WAN/LAN 1 x 10Gbps for LAN 3 x 2.5Gbps for LAN 1 x RJ45 10/100/1000Mbps for LAN |
Product Type | WiFi 7 Gaming Router |
Warranty | 3 Years Limited Warranty |
Wifi Ghz/Mbps | 2.4GHz BE: 4x4 (Tx/Rx) 4096 QAM 20/40MHz, up to 1376Mbps 5G-1Hz BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160MHz, up to 5764Mbp 5G-2Hz BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160MHz, up to 5764Mbp 6GHz BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160/320MHz, up to 11529Mbp |
Antenna | External antenna x 8 |
Buttons | WPS Button, Reset Button, Power Switch, LED control Button |
Dimension | 350.41 x 350.41 x 220.6 mm |
LED Indicator | WAN(Internet) x1 10G LAN x1 1G/2.5G LAN x1 6GHz x1 5GHz-1 x 1 5GHz-2 x 1 2.4GHz x1 Power x1 |
Memory | 256 MB Flash and 2 GB RAM |
Network Standard | WiFi 6 (802.11ax) WiFi 7 (802.11be) IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11ac IPv4 IPv6 |
Operating Frequency | 2.4 GHz / 5 GHz / 6 GHz |
Power Supply | AC Input : 110V~240V(50~60Hz), DC Output : 19.5 V with max. 3.33 A current |
Processor | 2.6GHz quad-core processor |
Security | WiFi Encryption : WPA/WPA2/WPA3 Personal WPA/WPA2/WPA3 Enterprise Open System &OWE, WPS, Let's Encrypt, DNS-over-TLS, SSH, Security Scan, Firewall • Maximum Firewall Keyword Filter : 64 • Maximum Firewall Network Service Filter : 32 • Maximum Firewall URL Filter : 64 |
Transmit / Receive | 2.4GHz 4x4, 5GHz-1 4x4, 5GHz-2 4x4, 6GHz 4x4 |
Weight | 2000 g |
