| Management features |
|---|
| Reset button | Yes |
| Switch layer | L2/L3 |
| Quality of Service (QoS) support | Yes |
| Multicast support | Yes |
| Ports & interfaces |
|---|
| SFP+ module slots quantity | 4 |
| Basic switching RJ-45 Ethernet ports quantity | 22 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| Power connector | AC/DC |
| 2.5G Ethernet (copper) ports quantity | 22 |
| 10G Ethernet (copper) ports quantity | 2 |
| Network |
|---|
| Networking standards | IEEE 802.1x |
| VLAN support | Yes |
| Rate limiting | Yes |
| Port mirroring | Yes |
| Flow control support | Yes |
| Broadcast storm control | Yes |
| 10G support | Yes |
| Virtual LAN features | Voice VLAN |
| IGMP snooping | Yes |
| Data transmission |
|---|
| Switching capacity | 230 Gbit/s |
| Jumbo frames support | Yes |
| Static route | Yes |
| Forwarding rate | 171.12 Mpps |
| Throughput | 115 Gbit/s |
| Security |
|---|
| Loop protection | Yes |
| IGMP snooping | Yes |
| DHCP features | DHCP relay, DHCP snooping, DHCP guarding |
| Multicast features |
|---|
| Multicast support | Yes |
| Design |
|---|
| Reset button | Yes |
| Rack mounting | Yes |
| Stackable | Yes |
| Display type | LCM |
| Product colour | Grey |
| Form factor | 1U |
| LED indicators | Link, Speed, Status |
| Housing material | SGCC |
| Power |
|---|
| Power consumption (max) | 56 W |
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Redundant power supply (RPS) support | Yes |
| Power source | AC/DC/PoE |
| Power connector | AC/DC |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) power per port | 15.4 W |
| Power over Ethernet (PoE) | Yes |
| Total Power over Ethernet (PoE) budget | 600 W |
| Power over Ethernet (PoE) voltage | 57 V |
| Power over Ethernet 4PPoE (PoE++) ports quantity | 24 |
| Operational conditions |
|---|
| Operating temperature (T-T) | -5 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Virtual LAN features |
|---|
| VLAN support | Yes |
| Virtual LAN features | Voice VLAN |
| Weight & dimensions |
|---|
| Width | 442.4 mm |
| Depth | 400 mm |
| Height | 44 mm |
| Weight | 6.4 kg |
| Packaging content |
|---|
| Rack mount kit | Yes |
| Cables included | Power |
| Performance |
|---|
| Stackable | Yes |
| Technical details |
|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Certificates |
|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Packaging data |
|---|
| Rack mount kit | Yes |
| Cables included | Power |
