All stock codes associated to this product
DECO-X20, DECOX20, 6935364052430
| Design |
|---|
| Product colour | White |
| LED indicators | Power |
| Antenna type | Internal |
| Antennas quantity | 4 |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Reset button | Yes |
| Certification | FCC, IC, NCC, BSMI, IDA, RCM, JPA, JRF, VCCI, KC |
| Product type | Mesh router |
| Transmit power | FCC: <30 dBm, CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz) |
| Wireless LAN features |
|---|
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Security algorithms | WPA-PSK, WPA2-PSK, WPA3 |
| Number of guest networks (5 GHz) | 1 |
| Number of guest networks (2.4 GHz) | 1 |
| WLAN data transfer rate (first band) | 1201 Mbit/s |
| WLAN data transfer rate (second band) | 574 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Guest access | Yes |
| WLAN data transfer rate (max) | 1775 Mbit/s |
| Features |
|---|
| DHCP client | Yes |
| DHCP server | Yes |
| Processor cores | 4 |
| Quality of Service (QoS) support | Yes |
| Firewall security | SPI |
| Number of guest networks (5 GHz) | 1 |
| Number of guest networks (2.4 GHz) | 1 |
| Parental control | Yes |
| Built-in processor | Yes |
| Protocols |
|---|
| DHCP client | Yes |
| DHCP server | Yes |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 2 |
| DC-in jack | Yes |
| Ethernet WAN | Yes |
| Power |
|---|
| AC adapter input current | 0.4 A |
| AC adapter output voltage | 12 V |
| AC adapter output current | 1 A |
| Certificates |
|---|
| Certification | FCC, IC, NCC, BSMI, IDA, RCM, JPA, JRF, VCCI, KC |
| Compliance certificates | CE, RoHS |
| Sustainability |
|---|
| Sustainability compliance | Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Weight & dimensions |
|---|
| Width | 110 mm |
| Depth | 110 mm |
| Height | 114 mm |
| Package width | 220 mm |
| Package depth | 194 mm |
| Package height | 125 mm |
| Package weight | 1.01 kg |
| Packaging content |
|---|
| AC adapter included | Yes |
| Ethernet cable | Yes |
| Number of products included | 1 pc(s) |
| Number of units included | 1 pc(s) |
| Packaging data |
|---|
| Package width | 220 mm |
| Package depth | 194 mm |
| Package height | 125 mm |
| Package weight | 1.01 kg |
| Technical details |
|---|
| Sustainability compliance | Yes |
| Harmonized System (HS) code | 85171800 |
| Compliance certificates | CE, RoHS |
| Logistics data |
|---|
| Harmonized System (HS) code | 85171800 |
Meet the Next-Gen Mesh Wi-FiNext-Gen AX1800 Whole Home Mesh Wi-Fi 6 System
Advanced Mesh Powered by Wi-Fi 6Armed with Wi-Fi 6 technology, Deco whole home mesh Wi-Fi is designed to deliver a huge boost in coverage, speed, and total capacity. Get on the latest mesh Wi-Fi to enjoy the future network that loads faster and connects more.
Wi-Fi Dead Zone KillerWith clearer and stronger signals enhanced by BSS Color and Beamforming, Deco X20 boosts broader whole home Wi-Fi up to 200 sqm (1-pack). Wireless connections and optional Ethernet backhaul work together to link Deco units, providing even faster network speeds and truly seamless coverage. Want more coverage? Simply add another Deco.
True Seamless Roaming for Greater ExperiencesTP-Link Mesh means Deco units work together to form one unified network. Your phone or tablet automatically connects to the fastest Deco as you move through your home, creating a truly seamless Wi-Fi experience.
More Connections for Immersive StreamingEnjoy a more efficient network with 4× the average throughput on connected devices in dense environments thanks to Wi-Fi 6 technology△. Deco X20 is tested to connect over 150 devices without dragging down performance.
Faster Wi-Fi 6 Speed = No WaitThe latest 1024-QAM and higher symbol rate combines to boost speeds up to 1.8 Gbps–ideal for bandwidth-intensive tasks like cloud gaming and 4K UHD video. Families will enjoy immersive live-streaming with flawless video and clear audio without buffering.
Greatly Red uced Lag, More FunWi-Fi 6 brings stable and responsive Wi-Fi connections to tomorrow's hyper-connected home. Enjoy more responsive gaming and seamless video chatting even when multiple compatible devices are connected and transmitting data at the same time.
Setup Just Got a Lot EasierUnbox Deco, install the app and then simply follow the on-screen directions. Deco app will take care of the rest, getting your network up and running in minutes.
Wi-Fi Made EasyEasy ManagementManage your Wi-Fi at home or away on the Deco app, including seeing all connected devices, prioritizing your own, setting up a guest network, and more.
Voice ControlPair with Alexa to control Deco X20 with simple voice commands. Enjoy the convenient life.
All Decos Work TogetherDeco X20 is compatible with every other Deco model to form a mesh network. Expand mesh Wi-Fi coverage anytime by simply adding more Decos.
