Management features |
---|
Switch type | Managed |
Quality of Service (QoS) support | Yes |
Cloud-managed | Yes |
Ports & interfaces |
---|
Basic switching RJ-45 Ethernet ports quantity | 16 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Network |
---|
Networking standards | IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3i, IEEE 802.3x |
Number of VLANs | 32 |
VLAN support | Yes |
Port mirroring | Yes |
Link aggregation | Yes |
Flow control support | Yes |
Auto MDI/MDI-X | Yes |
10G support | No |
Auto-negotiation | Yes |
Virtual LAN features | MTU VLAN, Port-based VLAN, Tagged VLAN |
IGMP snooping | Yes |
Data transmission |
---|
MAC address table | 8000 entries |
Switching capacity | 32 Gbit/s |
Store-and-forward | Yes |
Jumbo frames support | Yes |
Packet buffer memory | 4 MB |
Forwarding rate | 23.8 Mpps |
Number of VLANs | 32 |
Security |
---|
IGMP snooping | Yes |
DHCP features | DHCP client |
Design |
---|
Rack mounting | Yes |
Product colour | Black |
Performance |
---|
Fanless | Yes |
Packet buffer memory | 4 MB |
Auto-negotiation | Yes |
Power |
---|
Power supply included | Yes |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
Power source | AC |
Power over Ethernet (PoE) |
---|
Power over Ethernet (PoE) | No |
Operational conditions |
---|
Operating temperature (T-T) | -5 - 50 °C |
Storage temperature (T-T) | -40 - 70 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 90% |
Virtual LAN features |
---|
Number of VLANs | 32 |
VLAN support | Yes |
Virtual LAN features | MTU VLAN, Port-based VLAN, Tagged VLAN |
Weight & dimensions |
---|
Width | 294 mm |
Depth | 140 mm |
Height | 44 mm |
Packaging content |
---|
User guide | Yes |
Cables included | AC |
Technical details |
---|
Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
Certificates |
---|
Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
Packaging data |
---|
User guide | Yes |
Cables included | AC |
