| Ethernet LAN features |
|---|
| Ethernet WAN | Yes |
| Ethernet LAN interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Full duplex | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Auto MDI/MDI-X | Yes |
| Cabling technology | 10/100Base-T(X) |
| DSL features |
|---|
| DSL WAN | No |
| Mobile network |
|---|
| SIM card slot | No |
| 3G/4G USB modem compatibility | No |
| Performance |
|---|
| Processor frequency | 580 MHz |
| Built-in processor | Yes |
| Internal memory | 128 MB |
| Flash memory | 16 MB |
| Processor architecture | MIPS 24Kc |
| WAN connection |
|---|
| Ethernet WAN | Yes |
| DSL WAN | No |
| SIM card slot | No |
| 3G/4G USB modem compatibility | No |
| WAN connection type | RJ-45 |
| Wireless LAN features |
|---|
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (max) | 300 Mbit/s |
| Wi-Fi band | Single-band (2.4 GHz) |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Network |
|---|
| Ethernet LAN interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11s, IEEE 802.11v, IEEE 802.3, IEEE 802.3az, IEEE 802.3u |
| Full duplex | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Auto MDI/MDI-X | Yes |
| Cabling technology | 10/100Base-T(X) |
| Auto-sensing | Yes |
| Ports & interfaces |
|---|
| USB port | No |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| RS-232 ports | 1 |
| Management features |
|---|
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Security |
|---|
| Security algorithms | AES-CCMP, EAP-TLS, OWE, SSH, TKIP, WPA-PSK, WPA2-EAP, WPA2-Enterprise-PEAP, WPA2-PSK, WPA3-EAP, WPA3-SAE |
| Protocols |
|---|
| DHCP server | Yes |
| DHCP client | Yes |
| Design |
|---|
| Product type | Industrial router |
| LED indicators | LAN, Power, WAN |
| Housing material | Aluminium |
| Product colour | Black |
| Indication light | Yes |
| International Protection (IP) code | IP30 |
| Certificates |
|---|
| Certification | CE/RED, UKCA, CB, RCM, FCC, IC, EAC, UCRF, WEEE |
| Other features |
|---|
| Internal memory | 128 MB |
| Flash memory | 16 MB |
| Antenna |
|---|
| Antenna design | External |
| Antennas quantity | 1 |
| Antenna connector type | RP-SMA |
| Features |
|---|
| Processor frequency | 580 MHz |
| Certification | CE/RED, UKCA, CB, RCM, FCC, IC, EAC, UCRF, WEEE |
| Built-in processor | Yes |
| Internal memory | 128 MB |
| Flash memory | 16 MB |
| Processor manufacturer | MediaTek |
| Processor architecture | MIPS 24Kc |
| Internal memory type | DDR2 |
| Power |
|---|
| Power source type | DC, PoE |
| Operational conditions |
|---|
| Operating temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions |
|---|
| Width | 113.1 mm |
| Weight | 149.2 g |
| Height | 25 mm |
| Depth | 68.6 mm |
