Ethernet LAN features |
---|
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Cabling technology | 10/100/1000Base-T(X) |
Network |
---|
Network address translation (NAT) | Yes |
Short Message Service (SMS) | Yes |
Auto MDI/MDI-X | Yes |
Networking standards | IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Cabling technology | 10/100/1000Base-T(X) |
VLAN support | Yes |
Ethernet interface type | Gigabit Ethernet |
Performance |
---|
Operating system installed | RutOS |
Internal memory type | DDR3 |
Flash memory | 16 MB |
Internal memory | 256 MB |
WAN connection |
---|
SFP WAN | No |
Ethernet WAN | Yes |
DSL WAN | No |
SIM card slot | Yes |
3G/4G USB modem compatibility | No |
Mobile network |
---|
Mobile network generation | 5G |
Short Message Service (SMS) | Yes |
4G standard | LTE |
Management features |
---|
Web-based management | Yes |
Universal Plug and Play (UPnP) | Yes |
Reset button | Yes |
Quality of Service (QoS) support | Yes |
Ports & interfaces |
---|
Power over Ethernet (PoE) ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 2 |
Protocols |
---|
DHCP server | Yes |
DHCP client | No |
Routing protocols | BGP, EIGRP, NHRP, OSPFv2, RIP-1, RIP-2 |
DMZ support | Yes |
Security |
---|
Network address translation (NAT) | Yes |
Security algorithms | AES, CAST, DES, HTTPS, IPSec, SSH, SSL/TLS, TLS |
URL filtering | Yes |
System event log | Yes |
Firewall | Yes |
DoS attack prevention | Yes |
Technical details |
---|
Compliance certificates | CB, EAC, RCM, UKCA, WEEE |
Certificates |
---|
Compliance certificates | CB, EAC, RCM, UKCA, WEEE |
Features |
---|
Operating system installed | RutOS |
Internal memory type | DDR3 |
Flash memory | 16 MB |
Internal memory | 256 MB |
Design |
---|
Housing material | Plastic, Polycarbonate (PC) |
Product colour | White |
Power |
---|
Power over Ethernet (PoE) | Yes |
Power consumption (typical) | 2.5 W |
Power consumption (max) | 9 W |
Operational conditions |
---|
Operating temperature (T-T) | -40 - 55 °C |
Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions |
---|
Width | 110 mm |
Depth | 235 mm |
Height | 49.3 mm |
Weight | 385 g |
