Management features |
---|
Reset button | Yes |
Switch layer | L3 |
Ports & interfaces |
---|
SFP+ module slots quantity | 2 |
Basic switching RJ-45 Ethernet ports quantity | 16 |
Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
Gigabit Ethernet (copper) ports quantity | 12 |
Power connector | AC/DC |
2.5G Ethernet (copper) ports quantity | 4 |
Network |
---|
Networking standards | IEEE 802.1x |
VLAN support | Yes |
Rate limiting | Yes |
Port mirroring | Yes |
Flow control support | Yes |
Broadcast storm control | Yes |
10G support | Yes |
Virtual LAN features | Voice VLAN |
IGMP snooping | Yes |
Data transmission |
---|
Switching capacity | 84 Gbit/s |
Jumbo frames support | Yes |
Static route | Yes |
Forwarding rate | 62.496 Mpps |
Throughput | 42 Gbit/s |
Security |
---|
Loop protection | Yes |
IGMP snooping | Yes |
Access Control List (ACL) | Yes |
DHCP features | DHCP relay, DHCP snooping |
Design |
---|
Reset button | Yes |
Rack mounting | Yes |
Stackable | Yes |
Display type | LCM |
Product colour | Grey |
Form factor | 1U |
LED indicators | Link, Network, Speed, Status |
Housing material | SGCC |
Power |
---|
Power consumption (max) | 50 W |
Power supply included | Yes |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
Redundant power supply (RPS) support | Yes |
Power source | AC/DC |
Power connector | AC/DC |
Power over Ethernet (PoE) |
---|
Power over Ethernet (PoE) | No |
Operational conditions |
---|
Operating temperature (T-T) | -5 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Virtual LAN features |
---|
VLAN support | Yes |
Virtual LAN features | Voice VLAN |
Weight & dimensions |
---|
Width | 325.1 mm |
Depth | 160 mm |
Height | 43.7 mm |
Weight | 1.95 kg |
Packaging content |
---|
Rack mount kit | Yes |
Cables included | Power |
Performance |
---|
Stackable | Yes |
Technical details |
---|
Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
Certificates |
---|
Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
Packaging data |
---|
Rack mount kit | Yes |
Cables included | Power |
