| General |
| User Interface |
Graphical LCD with blue backlight and text in English, French, German, Russian and Spanish |
| LEDs |
Four status-indicating LEDs |
| Topology |
True online, double-conversion |
| Diagnostics |
Full system self-test |
| UPS Bypass |
Automatic bypass |
| Dimensions |
See models table |
| Rail Kit |
Included with all rackmount units |
| Electrical Input |
| Nominal Voltage |
220240V |
| Voltage Range |
160276 Vac (with load PF of 0.7) |
| Power Draw of UPS (full load) |
3.0A @230V
4.3A @230V
6.5A @230V
8.7A @230V
10.9A @230V
13.0A @230V |
| Dedicated Circuit Breaker Rating |
7002000 VA: 10A
3000 VA: 16A |
| Frequency |
50/60 Hz |
| Frequency Range |
4565 Hz |
| Electrical Output |
| Power Factor |
0.9 |
| On Utility Voltage Regulation |
3% of nominal |
| On Battery Voltage Regulation |
3% of nominal |
| Efficiency |
>95% in high-efficiency mode; >86% in online mode |
| Frequency Regulation |
3% Hz online |
| Load Crest Factor |
3 to 1 |
| Battery |
| Battery Type |
VRLA 12V/9 Ah (both internal and external) |
| Battery Runtime |
see runtime table |
| Battery Replacement |
Hot-swappable internal and external batteries |
| Start-On-Battery |
Allows start of UPS without utility input |
| Communications |
| Serial Port |
RS-232 standard, for interface to power management software |
| USB Port |
HID standard, for communicating with Windows XP & Vista |
| Relay Output |
Common alarm standard |
| Communications Slot |
Optional communication slots (BD Slot) |
| Optional Communication Cards |
SNMP/Web card for direct control and monitoring in SNMP-based networks, monitoring of UPS status and meters through Web browser interface Relay card for integration to industrial environment and building management systems, remote shutdown for IBM AS/400 systems |
| Environmental |
| Safety Markings |
CE, GS |
| EMC Markings |
CE (per IEC/EN62040-2: Emissions, Category C1; Immunity, Category C2) |
| Audible Noise |
<50 dB |
| Ambient Operating |
-20C to +40C with batteries and -25C to +55C without batteries |
| Storage Temperature |
590% non-condensing |
