ATEN 8-Port VanCryst HDMI Video Switch
  • HDTV resolutions of 480p, 720p, 1080i, 1080p (1920x1080); VGA, SVGA, SXGA, UXGA, and WUXGA (1920x1200)

IMG 1 of 1
No Longer Available
Part Number:
126207
(?) Brand:
ATEN
Manuf No:
VS0801H
Shipping Weight:
2 KG (Includes product packaging)
Estimate Shipping
Details Files Finance Images & Video
All stock codes associated to this product
VS0801H, KVAVS0801H, KVA-VS-0801H, 4710423776326
  8-Port HDMI Switch
  With more and more HDMI devices entering the Home Theater market, the need for simultaneous access to different HDMI A/V sources is becoming increasingly important. Now, the VS0801H 8-port HDMI Switch offers an easy and affordable way to add HDMI capabilities to your home theater system by allowing you to switch easily between up to eight HDMI A/V sources (such as an HD camcorder or satellite box, HD-DVD player, hi-def Blu-ray player, home theater PC, stand-alone streaming media player, gaming console, etc.) that are connected to your HDMI display.

The remote control and convenient front panel pushbuttons allow you to quickly and easily toggle between HDMI sources, while the front panel LEDs indicate the source device at a glance. Furthermore, for complete system and install integration, RS-232 control is standard through the VS0801H's built-in bi-directional RS-232 serial remote port that allows the switch to be controlled through a high-end controller, PC, and/or home automation/home theater software package.

  Features
Allows up to eight HDMI sources to be connected to one HDMI display
Quick and easy switching between HDMI sources via front panel pushbuttons or IR remote control
Built-in bi-directional RS-232 serial port for high-end system control
Supports Dolby True HD and DTS HD Master Audio
Up to 60 Hz refresh rate
Long-distance transmission - up to 20 m (24 AWG) and 15 m (28 AWG)
Superior video quality - HDTV resolutions of 480p, 720p, 1080i, 1080p (1920x1080); VGA, SVGA, SXGA, UXGA, and WUXGA (1920x1200)
Supports 12-bit Deep Color for HDMI formats
Plug-and-play - no software installation required
DDC compatible
HDMI 1.3b compliant
HDCP 1.1 compliant
HDMI CEC compliant
Signaling rates up to 2.25 Gbits in support of 1080p display
All-metal casing
Power On Detection - if one of the HDMI source devices is powered off, the VS0801H will automatically switch to the next powered on device
Easy and affordable way to add eight HDMI inputs to your home theater system
Rack Mountable
  Package Content
1x VS0801H 8-Port HDMI Switch
1x IR Remote Control Unit
1x Power Adapter
1x Rack Mount Kit
1x User Manual
1x Quick Start Guide
  Diagram
+ View enlargement
  Specification
Device Connections 8
Connectors Display HDMI In 8 x HDMI Type A Female (Black)
Device HDMI Out 1 x HDMI Type A Female (Black)
RS-232 Port 1 x DB-9 Female (Black)
Power 1 x DC Jack
LEDs Selected 8 (Green)
Video HDTV resolutions of 480p, 720p, 1080i, 1080p (1920x1080); VGA, SVGA, SXGA, UXGA (1600x1200), WUXGA (1920 x 1200)
Power Consumption DC5.3V, 3.71W
Environment Operating Temp. 0 - 50C
Storage Temp. -20 - 60C
Humidity 0-80% RH, Non-condensing
Physical
Properties		 Housing Metal
Weight 1.75 kg
Dimensions ( L x W x H ) 43.20x 15.40 x 4.40 cm
