4-Port HDMI Switch |
|
 |
The VS481A 4 Port HDMI Switch allows you to quickly and easily share your HDMI display device with 4 HDMI input sources. The VS481A allows convenient switching between digital devices such as DVD players, Satelite receivers, Digital Camcorder. The VS481A allows you to select the desired input source via a remote control unit and pushbuttons located on the switch. |
|
|
|
 |
Features |
 |
|
|
|
Allows up to four HDMI A/V source to be connected to one HDMI display |
|
Toggle between A/V sources using remote control or front panel pushbuttons |
|
Supports high-resolution video - HDTV resolutions of 480p, 720p, 1080i, 1080p (1920x1080); VGA, SVGA, SXGA, UXGA (1600x1200) and WUXGA(1920x1200) |
|
Supports 12-bit Deep Color for HDMI formats |
|
Supports Dolby True HD and DTS HD Master Audio |
|
Up to 60 Hz refresh rate |
|
Long distance transmission - up to 20m (24 AWG) and 15m (28 AWG) |
|
Built-in bi-directional RS-232 serial remote port for high-end system control |
|
Plug-and-play - no software installation required |
|
DDC Compatible |
|
HDMI 1.3b compliant |
|
HDCP 1.1 compliant |
|
Supports HDMI Type A 19-pin female connector |
|
Signaling rates up to 2.25 Gbits in support of 1080p display |
|
All-metal casing |
|
LED indication of video source devices |
|
Easy and affordable way to add four HDMI inputs to your home theater system |
|
|
|
| |
Package Content |
|
|
|
|
1x HDMI Switch |
|
1x HDMI Cable (1.8m) |
|
1x IR Remote Control Unit |
|
1x Power Adapter |
|
1x User Manual |
|
1x Quick Start Guide |
|
|
|
|
Diagram |
|
|
|
|
|
Specification |
|
|
|
| Display Connections |
1 |
| Connectors |
Device |
HDMI In |
4 x HDMI Type A Female (Black) |
| Display |
HDMI Out |
1 x HDMI Type A Female (Black) |
| RS-232 Port |
1 x DB-9 Female (Black) |
| Power |
1 x DC Jack |
| LEDs |
On Line |
4 (Orange) |
| Selected |
4 (Green) |
| Video |
HDTV resolutions of 480p, 720p, 1080i, 1080p (1920x1080); VGA, SVGA, SXGA, UXGA (1600x1200) , WUXGA(1920x1200) |
| Power Consumption |
DC 5.3 V, 2.4 W |
| Environment |
Operating Temp. |
0 - 50C |
| Storage Temp. |
-20 - 60C |
| Humidity |
0-80% RH, Non-condensing |
Physical
Properties |
Housing |
Metal |
| Weight |
0.47 kg |
| Dimensions ( L x W x H ) |
20.00 x 8.00 x 2.50 cm |
|
|
|
|
|
