ATEN CE700A KVM Console Extender - USB, 1280x1024 to 150m, Surge Protection

Our Price:

$313.45

RRP:

~~$359.00~~

You Save:

$45.55

Qty:

Add To Cart

or quickly purchase this product

Buy Now

Backorder

Part Number:

134678

(?) Brand:

ATEN

Manuf No:

S112271

Shipping Weight:

1 KG (Includes product packaging)
Estimate Shipping

Add to wishlist

Write a Review

Details Files Images & Video

Enter email address to be notified when this item is available again

Join waiting list

All stock codes associated to this product

CE700AATU, CE700A-AT-U, KVACE700A, KVA-CE-700A, S112271, 4710423776593

USB KVM Extender

The CE700A is a USB KVM Extender with superior video quality and built-in ESD and surge protection that allows access to a computer system up to 150 meters away from a remote USB console (USB keyboard, monitor, and USB mouse).

The CE700A improves on previous designs by: 1) incorporating 8KV/15KV ESD protection and 2KV surge protection; 2) providing superior video quality - up to 1920 x 1200 resolution; 3) using inexpensive Cat 5e cable, instead of bulkier, more expensive, standard cables, for a much neater, more convenient, more reliable data transfer connection; 4) it is able to sense the distance to the system and automatically adjusts the gain accordingly; and 5) it features a custom ASIC to ensure the utmost in reliability and compatibility.

Patent NO. :	US 7585176

Features

	Cat 5e cable connects the Local and Remote Units - up to 150m apart
	Dual console operation - control your system from both the local and remote USB keyboard, monitor, and mouse consoles
	Built-in ASIC for greater reliability and compatibility
	Auto Signal Compensation (ASC)
	USB Keyboard and USB Mouse Ports
	USB overcurrent detection and prevention
	Pushbutton operating mode selection (Local Unit only) - select between Local and Auto operating modes.
	Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV) and 2KV surge protection
	Automatic gain control - adjusts signal strength to compensate for distance
	High resolution video - up to 1920 x 1200@60Hz (30m ); 1600 x 1200@60Hz (100m); 1280 x 1024@60Hz (150m)
	Supports VGA, SVGA, SXGA, UXGA, WUXGA and multisyncmonitors; local monitor supports DDC; DDC2; DDC2B
	Rack mountableEasy to install - no software required - connecting cables to the devices is all it takes
	Multiplatform support - Windows, Linux

Package Content

	1x CE700AL USB KVM Extender (Local Unit)
	1x CE700AR USB KVM Extender (Remote Unit)
	2x Power Adapters
	1x USB KVM Cable (1.8m)
	2x Grounding Wires
	1x Rack Mount Kit
	1x User Manual
	1x Quick Start Guide

Diagram

+ View enlargement

Specification

Function			CE700AL	CE700AR
Connectors	Console Ports	Keyboard	1 x USB Type A Female (White)
		Video	1 x HDB-15 Female (Blue)
		Mouse	1 x USB Type A Female (White)
	KVM Ports	Keyboard/ Video / Mouse	1 x SPHD-17 Female (Green)	N/A
	Unit to Unit		1 x RJ-45 Female (Black)
	Power		1 x DC Jack (Black)
Pushbuttons	Operating Mode Selection		1 x Pushbutton	N/A
LEDs	Local		1 (Green)	N/A
	Remote		1 (Green)	1 (Green)
	Link		N/A	1 (Green)
Emulation	Keyboard / Mouse		USB
Power Consumption			DC5.3V/2.31W	DC5.3V/2.84W
Video			1920 x 1200 @ 60Hz (30m) 1600 x 1200 @ 60Hz (100m) 1280 x 1024 @ 60Hz (150m)
Environment	Operating Temp.		0 - 50C
	Storage Temp.		-20 - 60C
	Humidity		0-80% RH, Non-condensing
Physical Properties	Housing		Metal
	Weight		0.32 kg	0.31 kg
	Dimensions (L x W x H)		12.50 x 8.15 x 2.50 cm

No additional files, specification sheets, guides or documentation found for product.

Warranty: 24 months*

Full manufacturers warranty details are available at the manufacturers web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.
