ATEN VGA Over Cat 5 Repeater w. Audio - Adjustable Gain, Up to 150M, 1600x1200

IMG 1 of 1
No Longer Available
Part Number:
137125
(?) Brand:
ATEN
Manuf No:
VB552-AT-U
VB552ATU
Shipping Weight:
1 KG (Includes product packaging)
Estimate Shipping
Details Files Images & Video
All stock codes associated to this product
VB552ATU, VB552-AT-U, VB552, KVAVB552ATU, KVA-VB552-AT-U
VGA Over Cat 5 Repeater + Audio
The VB552 VGA Over Cat 5 Repeater +Audio is an audio/video signal extension device which is compatible with ATEN Cat 5 Audio/Video splitters. The VB552 extends the audio/video transmission range an extra 150m over Cat 5e (or higher) cables. The use of an additional repeater means the audio/video signals can be transmitted over even longer distances, up to 450m.

Furthermore, for longer distance installations where video signals may degrade, the VB552 has adjustable video gain and compensation controls to provide the sharpest video quality possible. An IR remote control also provides picture control at the remote site.

Rack-mountable, with two RS-232 channels on the unit for selection, and support for high video resolutions, the VB552 is the perfect solution to extend the range of your A/V and serial transmissions in any installation environment requiring VESA FDMI mount standards.

Features
Uses Cat 5e cable to extend audio/video signal
Extends the transmission range an extra 150m
High-quality video - up to 1920x1200@60Hz at 30m, 1600x1200@60Hz at 150m, 1280x1024@60Hz at 200m
Audio and serial enabled
Two gain control modes for sharpest picture quality
Video gain and compensation adjustable via OSD
IR receiver for quick and easy video quality adjustment
IR remote control for screen on/off and video adjustment at remote site
Provides two RS-232 channels for selection
Follows VESA FDMI mount standard
Supports DDC for the local monitor
Supports VGA, SVGA, XGA, SXGA, UXGA and multisync monitors
For use in combination with VS1504/VS1508 Audio/ Video splitter

Package Content
1x VB552 VGA Over Cat 5 Repeater + Audio
1x Power Adapter
1x Infrared Remote Control Handset
1x Infrared Receiver
1x IR Receiver Holder
1x Rack Mount Kit
1x User Guide

Diagram

Specification
Connectors Video Out 1 1 x HDB-15 Female (Blue)
Video Out 2 1 x HDB-15 Female (Blue)
Audio Out 1 1 x Mini Stereo Jack Female (Green)
Audio Out 2 1 x Mini Stereo Jack Female (Green)
RS-232 1 1 x DB-9 Male (Black)
RS-232 2 1 x DB-9 Male (Black)
IR Jack 1 x Mini Stereo Jack Female (Black)
Power 1 x DC Jack
Unit to Unit 2 x RJ-45 Female
Switches Video Gain/Up 1 x Pushbutton
Video Compensation/Down 1 x Pushbutton
LEDs Power 1 (Orange)
On Line 1 (Green)
Video 1920x1200@60Hz at 30m; 1600x1200@60Hz at 150m; 1280x1024@60Hz at 200m
Cable Distance 150 m
Power Consumption DC5.3V, 4.77W
Environment Operating Temp. 0-50C
Storage Temp. -20-60C
Humidity 0-80% RH, Non-condensing
Physical Properties Housing Metal
Weight 0.35 kg
Dimensions (L x W x H) 13.90 x 8.03 x 2.86 cm

No additional files, specification sheets, guides or documentation found for product.

Warranty: 1 Year Return to Base

Full manufacturers warranty details are available at the manufacturers web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.
