KN1000
KVM Over the NET
The KN1000 is a control unit that provides remote BIOS-level access to servers or "over-IP" capability to KVM switches that do not have built in over-IP functionality. It allows operators to monitor and access their computers from remote locations using a standard Internet browser or Windows/Java based application programs, for BIOS-level troubleshooting without the need for constant on site IT maintenance. In addition, the KN1000 offers out-of-band access including external modem support.
To help you manage and control multiple widely distributed servers efficiently from a remote console, a built-in single-port Power Switch allows remote power management of a server/installation connected locally to the KN1000, including turning servers On, Off and Rebooting. In addition, you can also add a PON (Power Over the NET) power management unit to manage the power status of even more devices. The KN1000 also provides serial console management over the internet which can remotely control serial console devices such as a network switch.
KN1000s Virtual Media function allows you to perform diagnostic testing, file transfer, and OS and application patches from a remote console. There is no need to physically load a CD directly to the server to perform data-related tasks. Conveniently and efficiently troubleshoot and resolve the problems at BIOS level from anywhere.
Both a Windows GUI Client and a Java Applet are also available in browser based and Windows application versions. They are provided for IP connection and login from anywhere on the net. Inclusion of a Java-based client ensures that the KN1000 is platform independent, and is able to work with practically all operating systems.
With these advanced features, the KN1000 is the fastest, most reliable, most cost effective way to remotely access and manage widely distributed multiple computer installations, such as kiosks and automated banking.
Patent No.
CN ZL 02129894.7 , CN ZL 02824593.8 , JP 4558319 , JP 4651633 , TW 199673 , TW 203183 , TW I273415 , US 6957287 , US 7142721 , US 7340556 , US 7350091 , US 7472217
Package Contents
- 1x KN1000 KVM Over the NET
- 2x Custom KVM Cable Sets
- 1x Custom Console Cable Set
- 1x USB 2.0 Virtual Media Cable
- 1x Power Adapter
- 1x Grounding Wire
- 1x Outlet Power Cord
- 1x Rack Mount Kit
- 1x Software CD
- 1x User Manual
- 1x Quick Start Guide
Features
The KN1000 is a control unit that provides remote BIOS-level access to servers or "over-IP" capability to KVM switches that do not have built in over-IP functionality. It allows operators to monitor and access their computers from remote locations using a standard Internet browser or Windows/Java based application programs, for BIOS-level troubleshooting without the need for constant on site IT maintenance. In addition, the KN1000 offers out-of-band access including external modem support.
To help you manage and control multiple widely distributed servers efficiently from a remote console, a built-in single-port Power Switch allows remote power management of a server/installation connected locally to the KN1000, including turning servers On, Off and Rebooting. In addition, you can also add a PON (Power Over the NET) power management unit to manage the power status of even more devices. The KN1000 also provides serial console management over the internet which can remotely control serial console devices such as a network switch.
KN1000s Virtual Media function allows you to perform diagnostic testing, file transfer, and OS and application patches from a remote console. There is no need to physically load a CD directly to the server to perform data-related tasks. Conveniently and efficiently troubleshoot and resolve the problems at BIOS level from anywhere.
Hardware
- Provides over-IP capability to servers or KVM switches that do not have built in over-IP functionality*
- Built in single port Power Switch
- Supports PS/2, USB, Sun Legacy (13W3)** and serial (RS-232) connectivity
- Local console provides PS/2, and USB keyboard and mouse support
- Supports multiplatform server environments: Windows, Mac, Sun, Linux and VT100 based serial devices
- Virtual Media Support
- High video resolution up to 1600 x 1200 @ 60Hz- 32 bit color depth for the local console; up to 1600 x 1200 @ 60Hzwith 24 bit color depth for remote sessions
* Compatible KVM Switches include the following: CS9134, CS9138, CS88A, CS1308, CS1316, CS1754*, CS1758, CS1708A, CS1716A, ACS1208A, ACS1216A, KH2508A, KH2516A, KH1508A, and KH1516A
- Some of the KN1000s features may not be supported, depending on the functionality of the connected KVM switch. (For example, some switches do not support virtual media.)
- Some features found on the connected KVM switches may not be supported on the KN1000. (For example, the CS1754s audio.)
** Requires CV130A converter purchase
Management
- Up to 64 user accounts up to 32 users simultaneously share the control
- End session feature administrators can terminate running sessions
- Event logging and Windows-based Log Server support
- Critical system event notification via SMTP email; SNMP trap and Syslog support
- Remote Firmware upgradable
- Serial console management serial terminal access. Access the KN1000 via a built-in serial viewer, or via third party software (such as PuTTY) for Telnet and SSH sessions
- PPP mode (modem) dial-in/dial out support for out-of-band, and low bandwidth operation
- Port Share Mode allows multiple users to gain access to a server simultaneously
- Integration with ALTUSEN CC2000 Management software
- Power Over the NET integration for remote power control
- Remote power on and off control function with Wake on LAN
- DDNS (Dynamic Domain Name System)
- Export/import user account and configuration settings
- Enable/disable browser operation
Ease-to-Use Interface
- Browser-based and AP GUIs offer a unified multilanguage interface to minimize user training time and increase productivity
- Multiplatform client support (Windows, Mac OS X, Linux, Sun)
- Multi-browser support: Internet Explorer, Chrome, Firefox, Safari, Opera, Mozilla, Netscape
- Browser-based UI in pure Web technology allows administrators to perform administrative tasks without pre-installed Java software package required
- Full-screen or sizable and scalable Virtual Remote Desktop
- Magic Panel
- Magic Panel
Advanced Security
- Smart Card /CAC Reader Support
- External authentication support: RADIUS, LDAP, LDAPS, and MS Active Directory
- 128-bit SSL encryption to protect password when users log in
- Flexible encryption design allows users to choose any combination of 56-bit DES, 168-bit 3DES, 256-bit AES, 128-bit RC4, or Random for independent KB/Mouse, video, and virtual media data encryption
- Support for IP/MAC Filter
- Supports password protection
- Private CA
Virtual Media
- Virtual media enables file applications, OS patching, software installation and diagnostic testing
- Works with USB enabled servers in operating system and BIOS level
- Supports USB 2.0 DVD/CD drives, USB mass storage devices, PC hard drives and ISO images
Virtual Remote Desktop
- BIOS-level access
- Video quality and video tolerance can be adjusted to optimize data transfer speed; monochrome color depth setting, threshold and noise settings for compression of the data bandwidth in low bandwidth situations
- Full screen video display or scalable video display
- Message Board for communication among remote users
- On-screen keyboard with multilanguage support
- Mouse Dynasync
- Exit Macros support
Specifications
| Connectors |
Console |
1 x SPHD-18 Male (Yellow) |
| KVM (Computer) |
1 x SPHD-17 Female (Yellow) |
| PON* |
1 x DB-9 Male (Black) |
| RS-232 |
1 x DB-9 Male (Black) |
| LAN |
1 x RJ-45 Female |
| Power Inlet |
1 x IEC320 C14 |
| Power Outlet |
1 x IEC320 C13 |
| Power |
1 x DC Jack |
| Virtual Media |
1 x USB Mini-B Female (Black) |
| Switches |
Reset |
1 x Semi-recessed pushbutton |
| LEDs |
Power |
1 (Orange) |
| Power Outlet |
1 (Orange) |
| Link |
1 (Green) |
| 10/100 Mbps |
1 (Orange/Green) |
| Emulation |
Keyboard/Mouse |
USB; PS/2 |
| Video |
1600 x 1200 @ 60 Hz; DDC2B |
| I/P Rating |
100240 VAC; 50/60 Hz, 10A |
| O/P Rating |
100240 VAC; 50/60 Hz; 9A |
| Power Consumption |
DC5.3V; 6.3W |
| Environment |
Operating Temp. |
0-40C
|
| Storage Temp. |
-20-60C |
| Humidity |
0 - 80% RH, Non-condensing |
Physical
Properties |
Housing |
Metal |
| Weight |
0.86 kg |
| Dimensions ( L x W x H ) |
30.85 x 8.15 x 4.20 cm |
Power Over the NET
