All stock codes associated to this product
U2412M, 2921934, 884116064244
Great performance, no matter how you look at it
Enjoy widescreen performance, any way you want it. With a 24" 16:10 panel, IPS technology and LED backlight, the U2412M provides a brilliant view, plus amazing adjustability to suit any style.
- Powerful: Experience IPS technology, featuring a wide viewing angle with high-quality color representation for a peerless viewing experience.
- Flexible: Pick the view that works best for you with an almost unlimited range of tilt, swivel, pivot and height adjustments.
- Customizable: Change your energy usage settings, text brightness and color temperature with the touch of a button to help conserve energy with this eco-designed arsenic-free and mercury-free panel.
Overview
Its okay to stare.
Whether for work or for play, the DellTM UltraSharpTM U2412M can deliver an unmatched viewing experience.
- Clearly outstanding: Watch your graphics come to life on a vast 24" (61cm) LED-backlit screen featuring a crystal-clear 1920x1200 resolution on a 16:10 widescreen aspect ratio so you cant lose screen area just because your customized applications support a different resolution.
- Contrasting view: Get ready for blur-free viewing with 2 million:1 (typical) high dynamic contrast ratio and 8ms with overdrive gray-to-gray (typical) response time that helps ensure crisp, sharp and ghost-free images.
- Colorful character: Enjoy an amazing range of rich, dramatic and accurate colors, thanks to IPS technology designed to give you color consistency across a broad viewing angle and a wide color gamut at 82% (typical).
- Premium Panel Guarantee: 100% replacement of Dell UltraSharp series monitors sold if any bright pixel is found, valid within the warranty period.
|
Your monitor, your style.
The ultimate in flexibility and customizability, the U2412M monitor can be adjusted to suit your workspace, tailored to suit your viewing preferences, and with its wide viewing angle, it can be viewed from almost any position.
Height adjustability: Raise or lower the U2412M to suit your workspace and your personal style with 4.5" of height adjustability.
Versatile connectivity: Connect a keyboard, mouse and other peripherals via USB ports, DisplayPort and DVI ports that can deliver outstanding image quality when viewing HD content.
Maximum flexibility: Position your monitor just the way you like with comfort-enabling features like tilt, swivel and rotate. IPS (in-plane switching) technology helps ensure a great view from almost any angle.
Supreme adaptability: Make colors cooler or warmer to suit your preference with the color temperature slider, while ‘Text mode’ automatically adjusts screen brightness to 150 nits, ideal for reading text.
Designed with the environment in mind.
Your workspace isnt the only environment that can benefit from the U2412M.
Environmental compliance:
The U2412M meets ENERGY STAR 5.1, EPEAT Gold and TCO Certified Displays 5 standards, and is also CECP and CEL compliant.
Power management:
PowerNap allows you to control monitor brightness level or to put it in sleep mode to conserve power, and Dynamic dimming software automatically dims onscreen brightness when displayed images are overly bright or white. You can even activate the energy usage bar to see the U2412Ms energy consumption.
Responsible construction:
The U2412M is made of environmentally responsible materials, consisting of an arsenic-free and mercury-free LED panel and halogen-free laminates in its circuit boards, designed to consume less energy than a conventional monitor.
Specifications:
| Dell UltraSharp 24 Monitor - U2412M |
|
|
DISPLAY
Diagonal Viewable Size:
24" (60.96 cm) viewable area
Aspect Ratio
Widescreen (16:10)
Panel Type, Surface:
IPS (In-Plane Switching), anti glare with hard coat 3H
Optimal Resolution:
1920 x 1200 at 60 Hz
Contrast Ratio:
1000 : 1 (typical)
2,000,000:1 (dynamic)
Dynamic Contrast Ratio:
2 million:1 (Max)
Brightness:
300 cd/m2 (typical)
Response Time:
8ms (gray to gray) Typical
Max Viewing Angle (vertical/horizontal)
178 / 178
Color Support:
16.78M colors
Color Gamut
82% (CIE 1976)
Pixel Pitch:
0.27 mm
Device Type
Widescreen Flat Panel Display
|
 |
|
CONNECTIVITY
1 Digital Visual Interface connectors (DVI-D) with HDCP
1 DisplayPort(DP)
1 Video Graphics Array (VGA)
1 USB 2.0 upstream port
4 USB 2.0 downstream ports
DC power connector for Dell Soundbar
|
|
STAND
Adjustability
Height-adjustable stand, tilt , swivel , pivot and built in cable-management
Flat Panel Mount Interface
VESA Mount
|
|
SECURITY
Security port (cable lock sold separately)
Anti-theft stand lock slot (to panel)
|
|
|
SIZE AND WEIGHT
Dimensions with stand (H x W x D):
20.22 inches (513.5 mm) x 21.89 inches (556.0 mm) x 7.10 inches (180.3 mm)
Dimension without stand: (H x W x D)
14.24 inches (361.6 mm) x 21.89 inches (556.0 mm ) x 2.56 inches (64.9 mm)
Preset Display Area (H x V)
20.3 inches (518.4 mm) x 12.7 inches (324.0 mm)
Weight (panel only - for VESA mount)
3.97 kg (8.73 lbs)
Weight (with packaging)
7.49kg (16.48 lbs)
|
|
| Environmental and Regulatory |
|
|
ELECTRICAL
Voltage Required
100 to 240 VAC / 50 or 60 Hz 3Hz / 1.5 A (Max)
Power Consumption (Operational)
38 W (typical) / 72 W (maximum)
Power Consumption Stand by / Sleep
Less than 0.5 W
|
|
|
ENVIRONMENTAL
Temperature Range Operating:
0 to 40 C (32 to 104F)
Temperature Range Non-operating:
Storage: -20 to 60 C (-4 to 140 F)
Shipping: -20 to 60 C (-4 to 140 F)
Humidity Range Operating:
10% - 80% (non-condensing)
Humidity Range Non-operating:
Storage: 5% to 90% (non-condensing)
Shipping: 5% to 90% (non-condensing)
Altitude Operating:
3,048 m (10,000 ft) max
Altitude Non-operating:
10,668 m (35,000 ft) max
|
|
COMPLIANCE AND STANDARDS
ENERGY STAR 5.1
EPEAT Gold
TCO Certified Displays
Product Safety, EMC and Environmental Datasheets
Dell Regulatory Compliance Home Page
Dell and the Environment
|
|
|
WHAT'S IN THE BOX
|
Monitor with stand
Power cable
DVI cable
USB cable
VGA Cable
Drivers and Documentation media
Quick Setup Guide
Safety Information
|
|
 |
|
|
WARRANTY
3-Year Advanced Exchange4 Service and Premium Panel Guarantee
|
|
