Display system |
3 LCD system |
Display device - Size of effective display area |
0.59 (15 mm) x 3 BrightEra Aspect ratio: 16:10 |
Display device - Number of pixels |
3,072,000 (1280 x 800 x 3) pixels |
Projection lens - Focus |
Manual |
Projection lens - Throw ratio |
0.46:1 |
Light source |
Ultra high pressure mercury lamp 210 W type |
Recommended lamp replacement time*1 |
4000 H / 6000 H / 10000 H (Lamp mode: High / Standard / Low) |
Filter cleaning cycle*1 |
Max. 7000 H |
Screen size |
57 to 103 (0.55 m to 1.04 m) |
Light output (Lamp mode: High / Standard / Low) |
2600 lm / 2100 lm*2 / 1700 lm*2 |
Color light output (Lamp mode: High / Standard / Low) |
2600 lm / 2100 lm*2 / 1700 lm*2 |
Contrast ratio (full white / full black)*3 |
3000:1 |
Displayable scanning frequency - Horizontal |
14 kHz to 93 kHz |
Displayable scanning frequency - Vertical |
47 Hz to 93 Hz |
Display resolution - Computer signal input |
Maximum display resolution: UXGA 1600 x 1200 dots*4 Panel display resolution: 1280 x 800 dots |
Display resolution - Video signal input |
NTSC, PAL, SECAM, 480/60i, 576/50i, 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/60p, 1080/50p |
Color system |
NTSC3.58, PAL, SECAM, NTSC4.43, PAL-M, PAL-N |
Keystone correction |
Vertical: Max. +/- 10 degrees |
OSD language |
24-languages (English, Dutch, French, Italian, German, Spanish, Portuguese, Turkish, Polish, Russian, Swedish, Norwegian, Japanese, Simplified Chinese, Traditional Chinese, Korean, Thai, Vietnamese, Arabic, Farsi, Finnish, Indonesian, Hungarian, Greek) |
Computer and video signal input/output INPUT A |
RGB / Y PB PR input connector: Mini D-sub 15-pin (female), Audio input connector: Stereo mini jack |
Computer and video signal input/output INPUT B |
RGB input connector: Mini D-sub 15-pin (female), Audio input connector: Stereo mini jack |
Computer and video signal input/output INPUT C |
HDMI input connector: HDMI 19-pin, HDCP support Audio input connector: HDMI audio support |
Computer and video signal input/output S VIDEO IN |
S video input connector: Mini DIN 4-pin, Audio input connector: Pin jack (x2) (shared with VIDEO IN) |
Computer and video signal input/output VIDEO IN |
Video input connector: Pin jack, Audio input connector: Pin jack (x2) (shared with S VIDEO IN) |
Computer and video signal input/output OUTPUT |
Monitor output connector*5: Mini D-sub 15-pin (female), Audio output connector*6: Stereo mini jack (variable out) |
Control signal input/output, Others |
RS-232C connector: D-sub 9-pin (male) LAN connector: RJ-45, 10BASE-T/100BASE-TX USB: Type-A, Type-B Microphone input: Mini jack |
Speaker |
16 W x 1 (monaural) |
Operating temperature (Operating humidity) |
0C to 40C / 32F to 104F (20% to 80%; no condensation) |
Storage temperature (Storage humidity) |
-10C to +60C / -14F to +140F (20% to 80%) |
Power requirements |
AC 100 V to 240 V, 3.2 A to 1.3 A, 50 Hz / 60 Hz |
Power consumption (Lamp mode: High / Standard / Low) AC 100 V to 120 V |
291 W / 251 W*2 / 219 W*2 |
Power consumption (Lamp mode: High / Standard / Low) AC 220 V to 240 V |
281 W / 242 W*2 / 212 W*2 |
Standby mode power consumption (Standby mode: Standard / Low) AC 100 V to 120 V |
4.9 W / 0.5 W |
Standby mode power consumption (Standby mode: Standard / Low) AC 220 V to 240 V |
5.1 W / 0.5 W |
Heat dissipation AC 100 V to 120 V |
993 BTU |
Heat dissipation AC 220 V to 240 V |
959 BTU |
Outside dimensions |
W 365 x H 138.7 x D 310 mm (W 14 3/8 x H 5 15/32 x D 12 7/32 inches) (without protrusions) |
Mass |
4.4 kg / 9 lb 10 oz |
Supplied accessories |
RM-PJ8 Remote Commander (1), Lithium battery: CR2025 (1), AC Power Cord (1), Operating Instructions (CD-ROM) (1), Quick Reference Manual (1), Mini D-sub 15-pin cable (1), Projector Station for Network Presentation application (CD-ROM) (1) |
Replacement lamp |
LMP-E212 |
*1 |
The figures are the expected maintenance time and not guaranteed. They will depend on the environment or how the projector is used. |
*2 |
The values are estimate |
*3 |
This value is average. |
*4 |
Available for the VESA Reduced Blanking signal. |
*5 |
Not available in standby. From INPUT A and INPUT B. |
*6 |
Works as an audio switcher function. Output from a selected channel; not available in standby. |
