All stock codes associated to this product
SUVTP10KH1B2S, II20811, 731304257042
Smart-UPS VT
APC Smart-UPS VT 10kVA 400V w/1 Batt Mod Exp to 2, Start-Up 5X8, Int Maint Bypass, Parallel Capable
SUVTP10KH1B2S
APC Smart-UPS VT,8000 Watts /10 kVA,Input 400V 3PH /Output 400V 3PH, Interface Port DB-9 RS-232, Extended runtime model
Includes: Battery modules ship installed, CD with software, Installation guide, Network Management Card, Power modules ship installed, Start-Up Service, User Manual
Standard Lead Time: Usually Ships within 2 Weeks
Product Overview
SUVTP10KH1B2S Features
Parallel-capacity capable
Increases total power capacity by using multiple uninterruptible power supplies simultaneously.
Parallel-redundant capable
Power the connected equipment with multiple uninterruptible power supplies to increase system redundancy
Smart-UPS VT Features & Benefits
Dual mains input
Increases availability by allowing the UPS to be connected to two separate power sources.
Scalable runtime
Allows additional run time to be quickly added as needed.
Hot-swappable batteries
Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
Generator compatible
Ensures clean, uninterrupted power to protected equipment when generator power is used.
Automatic internal bypass
Supplies utility power to the connected loads in the event of a UPS power overload or fault.
Battery modules connected in parallel
Delivers higher availability through redundant batteries.
Battery replacement without tools
Enables fast battery replacement, lowering Mean Time to Repair (MTTR).
Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Shippable with modules installed
Enables pre-installation UPS staging and testing and faster installation.
Modular design
Provides fast serviceability and reduced maintenance requirements via self-diagnosing, field-replaceable modules.
Network manageable
Provides remote power management of the UPS over the network.
InfraStruXure Manager Compatible
Enables centralized management via the APC InfraStruXure Manager.
LCD display
Alpha-Numeric Display which displays system parameters and alarms.
Audible alarms
Provides notification of changing utility power and UPS power conditions
Programmable frequency
Ensures compatibility with different input frequencies.
LED status indicators
Quickly understand unit and power status with visual indicators.
SmartSlot
Customize UPS capabilities with management cards.
Input power factor correction
Minimizes installation costs by enabling the use of smaller generators and cabling.
Temperature-compensated battery charging
Prolongs battery life by regulating the charge voltage according to battery temperature.
Manual maintenance bypass
Reduces installation costs by eliminating the need for an external mechanical bypass.
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.
Frequency and voltage regulation
Gives higher application availability by correcting poor frequency and voltage conditions without using the battery.
Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
Cold-start capable
Provides temporary battery power when the utility power is out.
Specifications
Output Power Capacity
8000Watts /10 kVA
Max Configurable Power
8000Watts /10 kVA
Nominal Output Voltage
400V 3PH
Output Voltage Note
Configurable for 380 : 400 or 415 V 3 Phase nominal output voltage
Efficiency at Full Load
95.7%
Output Voltage Distortion
Less than 5% at full load
Output Frequency (sync to mains)
47 - 53 Hz for 50 Hz nominal
Other Output Voltages
380, 415
Topology
Double Conversion Online
Output Connections
| (1) Hard Wire 4-wire (3PH + G) |
|
| (1) Hard Wire 5-wire (3PH + N + G) |
|
| (1) Screw Terminals |
|
Output Voltage Tolerance
+/-1% static and +/- 5% at 100% load step
Output Voltage THD
< 2% for 0 to 100% linear load and < 5% for full non linear load
Overload Operation
60 seconds@ 125% and 30 seconds at 150%
Efficiency at Half Load
94.4%
Required Output Current Protection
20A
Bypass
Built-in Maintenance Bypass, Built-in Static Bypass
Nominal Input Voltage
400V 3PH
Input Frequency
40 - 70 Hz (auto sensing)
Input Connections
| Hard Wire 5-wire (3PH + N + G) |
|
Input voltage range for main operations
304 - 477V
Other Input Voltages
380, 415
Maximum Input Current
14A
Input Breaker Capacity
20A
Input Total Harmonic Distortion
Less than 5% for full load
Included Battery Modules
1
Available Battery Module Slots
1
Typical recharge time
5hour(s)
Nominal Battery Voltage
+/-192 V (split battery referenced to neutral)
End of Discharge Battery Voltage
+/-154 V
Extended Run Options
APC Smart-UPS VT 10kVA 400V w/1 Batt Mod Exp to 2, Start-Up 5X8, Int Maint Bypass, Parallel Capable
| Curve |
Part Number(s) |
| A |
SUVTP10KH1B2S |
| B |
SUVTP10KH1B2S
+ (1)SYBT4 |
| C |
SUVTP10KH1B2S
+ (1)SUVTXR6B6S |
| D |
SUVTP10KH1B2S
+ (2)SUVTBXR6B6S |
| E |
SUVTP10KH1B2S
+ (3)SUVTBXR6B6S |
Hover over the line on the graph above to view the runtime at any desired load
Estimated runtimes based on battery vendor data, at typical environmental conditions, with no electrical input and balanced PF = 0.8 output.
View Enlarged Graph
View Runtime Chart
Communications & Management
Interface Port(s)
DB-9 RS-232
Pre-Installed SmartSlot Cards
AP9631
Control panel
Multi-function LCD status and control console
Audible Alarm
Audible and visible alarms : configurable delays
Emergency Power Off (EPO)
Yes
Shipping Height
1643.00mm
Regulatory Approvals
EN 50091-2, EN/IEC 62040-1-1, EN/IEC 62040-2, EN/IEC 62040-3, ISO 14001, ISO 9001, VFI-SS-111
Standard Warranty
1 year repair or replace
