Imaging
Imaging Sensor/Effective Pixels
CMOS / 18.0 MP
Effective Sensor Size
22.3x 14.9 mm
A/D Resolution Power
14-bit
Colour Filter Size
Primary Colours, APS-C
35mm Focal Length Equivalent
1.6X
Image Recording
Medium
SD/SDHC/SDXC/UHS-I
Image Size
Large
Approx. 17.90 megapixels (5184 x 3456)
Medium
Approx. 8.00 megapixels (3456 x 2304)
Small 1
Approx. 4.50 megapixels (2592 x 1728)
Small 2
Approx. 2.50 megapixels (1920 x 1280)
Small 3
Approx. 350,000 pixels (720 x 480)
RAW
Approx. 17.90 megapixels (5184 x 3456)
Movie Shooting (8GB Card)
1920 x 1080 (FULL HD)
30/25/24 fps, 22min @ 330MB/min
1280 x 720 (HD)
60/50 fps, 22min @ 330MB/min
640 x 480 (HD)
30/25 fps, 1hr 32min @ 82.5MB/min
Viewfinder
Coverage (vertical/horizontal)
95%
Dioptric Adjustment
-3 to +1m dpt
Auto Focus
AF Points
9 AF points
Exposure Control
Shooting Modes
12 standard modes
Metering Segments
63 zone TTL full aperture
Metering Modes
Evaluative, Partial, Spot, Centre-weighted average
ISO Speed Range
ISO 100-12800 (expandable to ISO 25600)
Exposure Compensation
1/3 or 1/2-stop increments Normal: 5; Manual, AEB: 2
Shutter
Shutter Speed
1/4000 sec 30, bulb, X-sync 1/200 sec.
Flash Control
E-TTL II Autoflash
Yes
Built-in Flash / Guide Number
Yes / 9.4
Speed
Shooting Speed
4 fps
White Balance
Settings
8
WB Bracketing
Yes
General Features
LCD Monitor
3.0 TFT Colour Liquid Crystal (Approx. 1,040,000 dots)
Custom Functions/Settings
Aug-24
Integrated Cleaning System
Yes
Live View
Yes (Live View Shooting, Movie Servo AF, Remote Live View Shooting, Face Detection, AF Mode, Manual, Magnified View, Multi Aspect Ratio, Exposure Simulation display)
External Interface
Hi-Speed USB/ HDMI / Stereo Audio OUT/ External Microphone IN / Remote Control Terminal (RS-60E3)
Wireless Remote Control Shooting
Yes (RC-6)
Battery
Lithium Ion LP-E12
Chassis Material
Aluminium and polycarbonate with glass fibre
Dimensions (W x H x D) mm
116.8 x 90.7 x 69.4 mm
Weight excl. battery (g)
370
