- High-brightness, lower power consumption enhance always-on capabilities of laser projection
- Ideal for new applications such as digital signage
- Lamp-less operation reduces TCO
- Eco-friendly features, minimal maintenance and cost savings mean these projectors are still great for demanding integration applications such as higher education and corporate
- TileMatrix enables 4Kx2K resolution utilizing digital loop through capabilities
- Seamlessly blend multiple images with integrated edge blending capabilities
- Built-in HDBaseT enabels simplified installations with a single cable for video, audio, and control signals.
Technologies
3D Ready
When combined with active shutter glasses (NP02GL), this projector uses DLP Link™ technology, developed by Texas Instruments, to create 3D images.
6 Bayonet-Style Lenses
Allows for quick and easy lens exchange. Optional lenses enable the user to determine the appropriate lens to cover projection distances between 2.6 and 179.8 feet.
Advanced AccuBlend™
Ensures detailed images when non-native resolution sources are connected to the projector.
AutoSense™
Intuitively syncs the projector with most computer signals and features one-touch image optimization.
BrilliantColor™
Advanced video processing from Texas Instruments delivers exceptional picture management control for both progressive and interlaced sources, while making images more vibrant, colors more realistic and blacks richer with detail.
Built-In Closed Captioning
Enables decoding and display of text information from a video.
Built-in Wall Color Correction
Presets provide for adaptive color tone correction to display properly on non-white surfaces.
Cornerstone Correction
Allows for horizontal, vertical and diagonal image correction for aligned images even when the projector is set up at an angle to the screen.
DLP Technology
High contrast images (10,000:1) from the latest Texas Instruments DLP engine featuring BrilliantColor™ technology with improved color accuracy
Dual Computer Inputs
Ensures quick switching between presentations.
ECO Mode™
Extends lamp life, lowers audible noise and reduces total cost of ownership.
Edge Blending
Blend multiple projectors together to create not standard images
Extended Use
For use in applications up to and including 24x7 operation.
Geometric Correction
Allows you to project on spheres, cylinders, corner angles and more.
Landscape/Portrait Capable
Allows for distortion-free display of content in various orientations, creating new application opportunities.
Lens Shift
Vertical and horizontal lens shift enables flexible projector placement.
Open Pluggable Specification (OPS)
The first industry-wide standardization in option slots that allows for easier installation, use and maintenance of digital signage
PIP/POP/Side-by-Side
Picture-in-picture (PIP) allows for a second frame within the screen area. Picture-on-picture (POP) surrounds the standard frame with multiple frames. Side-by-side places two sources adjacent to one another.
Portrait Mode
Ability to install a projector in its side to create a 10:16 portrait image
Power Zoom and Focus
Simplifies installation and operation by easily adjusting the lens through the remote control.
Stacking Capabilities
Allows the projectors to boost an image’s brightness up to 20,000 lumens, which is ideal for larger-sized screens and environments with heavy ambient light. This feature also prevents the complete loss of an image, which can happen when using only one projector.
Tilt-Free Installation
Allows the projector to be rotated freely (360°) in order to point up or down depending on the installation requirements.
Wired Network Connection
Integrated RJ45 connection for quick connection to the LAN (10/100 base-T capability).
Specifications
| Optical |
| |
| |
| |
| |
| Display Technology |
DLP (0.67" DMD) |
| |
| Light Output(Lumens) |
6000 normal |
| |
| Resolution |
|
|
| Native |
WUXGA 1920 x 1200 |
| |
| Maximum |
WUXGA 1920 x 1200 |
| |
|
| |
|
| Contrast Ratio (up to) |
10,000:1 with auto iris |
| |
| Lamp Type |
Laser/Phosphor |
| |
| Lamp Life (up to) |
20,000 hours |
| |
| Screen Size (diagonal) |
40 to 300 in. / 1.02 to 12.7m |
| |
| Throw Ratio |
1.5 to 3.02 |
| |
| Projection Distance |
2.5 to 68.5 ft. / 0.74 to 20.9m |
| |
| Projector Angle |
10.3 to 10.8 tele / 13.7 to 14.5 wide |
| |
| Lens |
|
|
| Zoom |
1 to 2.01 |
| |
| Focus |
Manual |
| |
| F number, fnumber |
F=1.7 to 2.37, f=24.4 to 48.6mm |
| |
| Shift |
Mechanical -0.1 to +0.5 vertical, +/-0.3 horizontal |
| |
|
| |
|
| Keystone Correction |
+/- 40 horizontal, +/- 30 vertical |
| |
|
| |
| |
| Signal Compatibility/Connectivity |
| |
| |
| |
| |
| Scan Rate |
|
|
| Horizontal |
15-153 kHz |
| |
| Vertical |
48-120 Hz |
| |
|
| |
|
| Supported Video Standards |
NTSC, NTSC4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM |
| |
| SD/HD Video Signal Compatibility |
480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| |
| PC Signal Compatibility |
VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA |
| |
| Macintosh Compatibility |
Yes |
| |
| Input/Output Terminals |
|
|
| RGB1(analog) |
VGA 15-pin D-sub |
| |
| RGB2(analog) |
5-BNC |
| |
| RGB2(digital) |
HDMI w/HDCP |
| |
| RGB3(digital) |
HDMI w/HDCP |
| |
| RGB4(digital) |
DisplayPort w/HDCP |
| |
| RGB5(digital) |
HDBaseT |
| |
| Monitor out |
HDMI |
| |
|
| |
|
| External Control |
RS-232, IR, DDC/CI, USB |
| |
| Sync Compatiblity |
Separate Sync / Composite Sync / Sync on G |
| |
|
| |
| |
| Electrical |
| |
| |
| |
| |
| Power Requirements |
100-240V AC, 50/60 Hz |
| |
| Input Current |
6.8-2.5A |
| |
| Power Consumption (Normal/ECO Mode/Standby/Standby Power Saving) |
530W / 420W / 6W / 0.5W |
| |
|
| |
| |
| Mechanical |
| |
| |
| |
| |
| Optional Lenses |
NP33ZL, NP34ZL, NP35ZL, NP37ZL, NP38ZL |
| |
| Installation Orientation |
Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear |
| |
| Dimensions (WxDxH) |
19.1 x 22.6 x 8.5 in. / 484 x 575 x 217mm |
| |
| Net Weight |
35.3 lbs. / 18.5 kg |
| |
| Fan Noise |
39 dB normal / 34 dB eco |
| |
| Regulations |
USA UL 1950 FCC Class B, Canada CSA 950 (C-UL), NOM |
| |
|
| |
| |
| Environmental |
| |
| |
| |
| |
| Operating Temperature |
41-104F / 5-40C |
| |
| Humidity |
20-80% non-condensing |
| |
| Storage |
-14-122F / -10-50C |
| |
|
| |
| |
| Limited Warranty |
| |
| |
| |
| 3 years (excluding consumables). First year Instacare Service. |
