Built-in retractable OLED Tru-Finder viewfinder
View every scene in rich detail with the high contrast and bright, pop-up OLED Tru-Finder with approx. 638k dots resolution. The electronic viewfinder faithfully displays what will appear in your recording, including the effects of your camera settings, so you can accurately monitor the results. Use of aspherical lenses in the eyepiece optics raises performance and minimizes size, while a convenient eye sensor automatically switches between EVF and LCD screen, for easy operation.
High-quality movies1 w/ XAVC S, AVCHD and MP4 codes
Capture high quality HD movies1 in the XAVC S format. With 50Mbps Full HD (1920x1080) 60p high quality video recording, XAVC S enables beautiful video recording with minimal compression noise even in scenes with a lot of movement. Linear PCM is adopted for audio compression delivering incredible audio to match your video. The camera also records in AVCHD, ideal for HDTV and Blu-ray Disc burning, or your choice of highly compressed MP4 HD video ideal for web.
Simple connectivity to smartphones via Wi-Fi2 and NFC3
Wi-Fi connectivity allows you to control your camera with your compatible Smartphone or Tablet2. Frame your image on your devices LCD and control the cameras shutter. You can even transfer the images taken directly to your mobile device for quick editing and uploading - sharing has never been easier. With NFC3 (near field communication) - connectivity has been simplified to one-touch. Simply touch the camera to the compatible NFC enabled device to connect.
5-axis image stabilization greatly reduces blur
Get remarkably sharp images with Sonys Optical SteadyShot image stabilization for both stills and video. Additionally, intelligent Active Mode combines 5-axis* image stabilization with Sony's advanced frame-analysis technology to greatly reduce blur caused by camera shake when shooting movies allowing you to move along with the action and get clear images of your subject in motion even when zoomed in.
Selfie-ready multi-angle 3 Xtra Fine LCD display
Selfies have never been easier with a beautiful 3 (921k dots) Xtra Fine LCD Display that rotates up approx. 180. Easily frame for selfies or to shoot objects like pets at eye-level without having to get down on the ground. Simply scroll through menus and preview life thanks to the large display which delivers brilliant-quality still images and movies while enabling easy focusing operation.
P/A/S/M modes, customizable settings & Memory Recall mode
For creative flexibility, you can enter Program Auto (P), Aperture Priority (A), Shutter Speed Priority (S) or Manual Exposure (M) mode for manual shooting. MR (Memory Recall) mode is available for quick manual adjustment and a control ring - that can be assigned with various functions - such as manual focusing or step zooming, allow for superior control of your shooting experience.
Enhance features w/ downloadable camera apps
Get creative with PlayMemories Camera Apps4 by applying exciting artistic effects or retouching images with professional results, and then easily upload your photos to Facebook or Instagram. Enjoy added functionality with apps that include Time Lapse, Smart Remote Control, and Direct Upload.
Map your images with GPS tagged photos
Built-in GPS records location data and camera direction as you shoot movies and photos. With the GPS Log and the supplied PlayMemories Home software, you can track a photographic journey and later view the path and images on a map, showing you where they were taken. Images can also be displayed on Google Earth.
Capture the decisive moment with up to 10fps
Never miss that decisive moment; like a bat hitting a baseball or a fleeting smile. Capture full 18.2 megapixel resolution images at up to 10 frames per second, with an ultra-fast shutter lag of Approx. 0.008 sec.
Keep your subject in focus with Lock-On AF
Lock-On AF (Auto Focus) gives you the ability to select a focus point with subject recognition, then allows the camera to track and keep your subject in sharp focus even when in motion.
Product Specifications
Advanced Features
-
Image Stabilization : Optical SteadyShot
-
Photo Creativity : Yes
-
Intelligent Auto : Yes
-
Sweep Panorama : Intelligent Sweep Panorama (360)
-
Anti Motion Blur : Yes
-
Wi-Fi : Yes
-
Face Detection : Yes (eight faces max)
-
Smile Shutter technology : Yes
-
Picture Effects : Toy camera, Pop Color, Posterization, Retro Photo, Soft High-key, Partial Color, High Contrast Mono.
- Superior Auto : Yes
Convenience Features
Drive System
-
Continuous Shooting Speed : Approx. 10 fps (for up to 10 shots)
-
Shutter Speeds : iAuto (4" - 1/2000) / Program Auto (1" - 1/2000) / Aperture Priority (8" - 1/2000) / Shutter Priority (30" - 1/2000) / Manual (30" - 1/2000)
-
Self-timer : Off / 10sec. / 5sec. / 2sec. / 3 consecutive shots with 10sec. 5sec. or 2sec. delay selectable / 3 consecutive bracketing shots with 10sec. 5sec. or 2sec. delay selectable
- Drive Mode : Single, Continuous shooting, Self-timer, Self-timer(cont.) Bracket: Continuous, Single, White balance, DRO bracketing
Exposure System
-
D-Range Optimizer : Off, Dynamic Range Optimizer (Auto/Level 1-5), Auto High Dynamic Range: Off, Auto Exposure Difference, Exposure difference Level (1.0-6.0EV, 1.0EV step)
-
Exposure Compensation : +/- 3.0 EV (1/3 EV step)
-
Minimum Illumination : [Movie]: Auto: 6lux (Shutter Speed 1/30)
-
Exposure Settings : [Still] Intelligent Auto, Superior Auto, Program Auto, Aperture Priority,Shutter Speed Priority, Manual Exposure, MR(Memory Recall) 1,2,3, Movie Mode(Program Auto,Aperture Priority,Shutter Speed Priority,Manual Exposure), Panorama, Scene Selection
-
Scene Mode(s) : Portrait, Advanced Sports Shooting, Landscape, Sunset, Night Scene, Handheld Twilight, Night Portrait, Anti Motion Blur, Pet Mode, Gourmet, Beach, Snow, Fireworks, Soft Skin, High Sensitivity
-
Metering Modes : Multi Pattern, Center Weighted, Spot
-
Metering Sensitivity : EV 2 to 16 (at ISO100 equivalent)
-
ISO : [Still Image] Auto(ISO80-3200, selectable with upper / lower limit),80/100/200/400/800/1600/3200,Multi-Frame NR:Auto(ISO80-3200 same as selected range in Auto), 100/200/400/800/1600/3200/6400*3/12800*3
-
Noise Reduction : Long exposure NR High ISO NR: Normal / Low Multi Frame NR: Auto, ISO100-12800
-
Creative Style : Standard, Vivid, Portrait, Landscape, Sunset, Black & White, Sepia
-
ISO Sensitivity (Movie) : [Movie] Auto (ISO80-3200, selectable with upper / lower limit),80/100/200/400/800/1600/3200
-
White Balance Mode : Auto / Daylight / Shade / Cloudy / Incandescent / Fluor.: Cool White / Fluor.: Day White / Fluor.: Daylight / Flash / Custom / One Push, One Push Set
Flash
-
Flash Modes : Auto / Flash On / Slow Synchro / Flash Off / Rear Sync.
-
Flash Coverage : ISO Auto: Approx.0.3m to 5.4m (11 13/16 inches to 17 ft 8 19/32 inches) (W) / Approx.2.5m to 3.0 m (8 ft 2 27/64 inches to 9 ft 10 7/64 inches) (T)
Focus Control
-
AF Illuminator : Auto / Off
-
Focus Area : Wide / Center / Flexible Spot (S/M/L) / Expanded Flexible Spot
-
AF Modes : Single-shot AF, Continuous AF (Advanced sports & Movie Only), DMF, Manual Focus
Imaging Sensor
-
Processor : BIONZ X
-
Pixel Gross : 21.1MP
-
Color Filter System : RGB primary color mosaic filters
-
Effective Picture Resolution : 18.2MP
-
Imaging Sensor : 1/2.3" (7.82mm) Exmor R CMOS sensor
Interface
- NFC : Yes (NFC forum Type 3 Tag compatible, One-touch remote, One-touch sharing)
- HD Output : Multi / Micro USB Terminal Hi-Speed USB (USB2.0) Micro HDMI
- Wi-Fi : Yes (IEEE802.11b/g/n (2.4GHz band))
LCD Display
-
LCD Type : 3.0'' (7.5 cm) (4:3) / 921,600 dots / Xtra Fine / TFT LCD
-
Angle Adjustment : Up by approx. 180 degrees
-
Histogram : Yes (On / Off)
- Brightness Control : Manual (5 steps)
Optics/Lens
-
Digital Zoom : Still Image: 18M Approx.120x / 10M Approx. 161x / 5.0M Approx. 226x / VGA Approx. 459x / 13M (16:9) Approx.120x / 2.1M (16:9) Approx. 306x Movie: Approx. 120x
-
Optical Zoom : 30x (Optical Zoom during movie recording)
-
Macro Mode : Yes (Auto)
-
Minimum Focus Distance : iAuto: AF (W: Approx. 5cm (0.16 ft.) to Infinity, T: Approx. 250cm (8.20 ft.) to Infinity) / Program Auto: AF (W: Approx. 5cm (0.16 ft.) to Infinity, T: Approx. 250cm (8.20 ft.) to Infinity)
-
Lens Groups-Elements : 11 elements in 10 groups (including 5 aspheric elements)
-
Lens Type : ZEISS Vario-Sonnar T* Lens
-
Aperture (Max.) : F3.5 (W) - 6.4 (T)
-
Steady Shot Mode:Active : Yes
-
Clear Image Zoom : Still Image:18M Approx. 60x / 10M Approx. 80x / 5.0M Approx. 113x / VGA Approx. 459x / 13M (16:9) Approx. 60x / 2.1M (16:9) Approx.153x Movie: Approx. 60x
-
Aperture : iAuto (F3.5-F6.3(W)) / Program Auto(F3.5-F6.3(W) ) / Manual (F3.5-F8.0(W)) / Aperture Priority(F3.5-F8.0(W)) / Sutter Priority(F3.5-F6.3(W))
-
Focal Length (35mm equivalent) : [Still Image 3:2] f=25-750mm, [Still Image 4:3] f=24-720mm, [Still Image 16:9] f=26.5-795mm, [Still Image 1:1] f=27.5-825mm [Movie 16:9] f=26.5-795mm (SteadyShot Standard), f=28-1180mm (SteadyShot Active), f=31-1210mm (SteadyShot InteligentActive), [Movie 4:3] f=32.5-975mm (SteadyShot Standard), f=34.5-1450mm (SteadyShot Active), 38-1480mm (SteadyShot InteligentActive)
-
Aperture Blade : Iris diaphragm (5 blades)
Power
-
Power Requirements : AC 100V to 240V, 50/60 Hz, 70mA
-
Battery Type : NP-BX1
-
Power Consumption (in Operation) : Approx. 1.4W with LCD monitor and approx. 1.5W with viewfinder (CIPA standard)
-
Power Consumption (in View Finder Operation) : Still Images: Monitor: Approx. 390 / Approx. 195min.; ViewFinder: Approx. 360 / Approx. 180min. Movie (Actual shooting): Monitor: Approx. 70min.; ViewFinder: Approx. 75min. (In [MP4 28M] mode, max. continuous shooting time is approx. 20 min. and max. file size is 4GB.) Movie (Continuous shooting): Monitor: Approx. 105min.; ViewFinder: Approx. 115min. (In [MP4 28M] mode, max. continuous shooting time is approx. 20 min. and max. file size is 4GB.)
Recording
- Panorama Still Image Size : Sweep Panorama: Wide (7,152 x 1,080/4,912 x 1,920) Standard: (4,912 x 1,080/3,424 x 1,920), 360 (11,520 x 1,080)
- Microphone/Speaker : Stereo / mono
- Still Image Size 1:1 : 1:1 mode: 13M (3,664 x 3,664) / 7.5M (2,736 x 2,736) / 3.7M (1,920 x 1,920)
- Audio Format : XAVC S: LPCM 2ch AVCHD: Dolby Digital (AC-3) 2ch (Dolby Digital Stereo Creator) MP4: MPEG-4 AAC-LC 2ch
- Video Format : XAVC S / AVCHD format Ver.2.0 compatible / MP4
- Video Mode : AVCHD: 28M PS (1,920 x 1,080/60p) 24M FX (1,920 x 1,080/60i) 17M FH (1,920 x 1,080/60i) 24M FX (1,920 x 1,080/24p) 17M FH (1,920 x 1,080/24p) XAVC S: 60p 50M (1,920 x 1,080/60p) 30p 50M (1,920 x 1,080/30p) 24p 50M(1,920 x 1,080/24p) MP4: 28M (1,920 x 1,080/60fps) 16M (1,920 x 1,080/30fps) 6M (1,280 x 720/30fps)
- Color Space : sRGB
- Still Image Size 16:9 : 16:9 mode: 13M (4,896 x 2,752) / 7.5M (3,648 x 2,056) / 2.1M (1,920 x 1,080)
- Still Image Size 3:2 : 3:2 mode:16M (4,8963,264) / 8.9M (3,648 x 2,432) / 4.5M (2,592 x 1,728),
- Still Image File Format : JPEG (DCF Ver.2.0, Exif Ver.2.3, MRF Baseline complians)
- Media Type : Memory Stick Duo; Memory Stick PRO Duo; Memory Stick PRO Duo(High Speed); Memory Stick PROHG Duo; Memory Stick Micro; Memory Stick Micro (Mark2); SD Memory Card; SDHC Memory Card(UHS-I); SDXC Memory Card(UHS-I); microSD Memory Card; microSDHC Memory Card; microSDXC Memory Card
- Still Image Max Effective Resolution : Approx. 18.2 Megapixels
- Still Image Size 4:3 : 4:3 mode: 18M (4,896 x 3,672) / 10M (3,648 x 2,736) / 5M (2,592 x 1,944) / VGA
- Wind Noise Reduction : Off / On
Viewfinder
Weights and Measurements
- Dimensions (Approx.) : W x H x D: 4 1/8" x 2 3/8" x 1 7/16" (102.0 x 58.1 x 35.5mm)
- Weight (Approx.) : Approx. 8.6oz (245g) (Battery and Memory Stick DUO are included)
- Weight(Approx) (Main unit only) : Approx. 7.7oz (218g)
