HOME / Back -> Memory - RAM -> Notebook DDR-3 RAM -> Kingston

Kingston 8GB (2 x 4GB) PC3-17000 2133MHz DDR4 SODIMM RAM - 13-13-13 - HyperX Impact Series, Black Slim and Sleek Heatsink

IMG 1 of 1
No Longer Available
Part Number:
397667
(?) Brand:
Kingston Web Site
Manuf No:
HX421S13IBK2/8
Shipping Weight:
0.5 KG (Includes product packaging)
Estimate Shipping
Details Files Images & Video
Need assistance in selecting the correct RAM for your system?
Please use our Memory Configurators to ensure compatibility
All stock codes associated to this product
HX421S13IBK2/8
HX421S13IBK2/8

8GB (4GB 512M x 64-Bit x 2 pcs.)

DDR4-2133 CL13 260-Pin SODIMM Kit

DESCRIPTION

HyperX HX421S13IBK2/8 is a kit of two 512M x 64-bit (4GB) DDR4-2133 CL13 SDRAM (Synchronous DRAM) 1Rx8, memory modules, based on eight 512M x 8-bit DDR4 FBGA components. Total kit capacity is 8GB. Each module kit supports Intel Extreme Memory Profiles (Intel XMP) 2.0. This module has been tested to run at DDR4-2133 at a low latency timing of 13-13-13 at 1.2V. Additional timing parameters are shown in the PnP Timing Parameters section below. The JEDEC standard electrical and mechanical specifications are as follows:

PnP JEDEC TIMING PARAMETERS:

JEDEC/PnP: DDR4-2133 CL13-13-13 @1.2V
XMP Profile #1: DDR4-2133 CL13-13-13 @1.2V

FEATURES

Power Supply: VDD = 1.2V Typical
VDDQ = 1.2V Typical
VPP - 2.5V Typical
VDDSPD = 2.25V to 3.6V
On-Die termination (ODT)
16 internal banks; 4 groups of 4 banks each
Bi-Directional Differential Data Strobe
8 bit pre-fetch
Burst Length (BL) switch on-the-fly BL8 or BC4(Burst Chop)
Height 1.18 (30.00mm)

Specifications

CL(IDD): 13 Cycles
Row Cycles Time (tRCmin): 46.5ns (min.)
Refresh to Active/Refresh, Command Time (tRFCmin): 260ns (min.)
Row Active Time (tRASmin): 33ns (min.)
Maximum Operating Power: TBD W*
UL Rating: 94V - 0
Operating Temperature: 0C to 85C
Storage Temperature: -55C to + 100C



No additional files, specification sheets, guides or documentation found for product.

Warranty: Lifetime warranty

Full manufacturers warranty details are available at the manufacturers (Kingston) web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.
