Featuring a brightness of 3200 ANSI Lumens and a high contrast ratio of 13000:1, the cost-effective and eco-friendly MX507 offers a stunning full-screen presentation with the finest details regardless of the ambient light level.





Offering lower TCO and optimized projection through dynamic power saving, uncompromised brightness, exquisite picture quality and optimized lamp life - SmartEcoTechnology has perfected what a DLP projector can do. With this innovation, schools and corporations are able to save up to 70% of lamp power consumption and lower maintenance costs through dynamic power saving features while bringing an ultra-vivid viewing experience into every presentation.







The SmartEco Mode, which cleverly adjusts the lamp power to maximize power saving by delivering the best contrast and brightness performance using only as much light as needed.





296W Projector Power

Consumption by Average

Enhanced Details in Darkened Scenes

163W Projector Power Consumption by Average



(Source: 2010 Philips white paper)



LampSave Mode



Projector lamp replacement costs make up the biggest part of the total cost of projector ownership. The LampSave Mode is designed to adjust the lamp power dynamically by content brightness level to extend projector lamp life significantly by 50%! The lamp replacement frequency is also reduced by up to 50% to lower the replacement costs.







The Eco Blank mode allows teachers to blank the projection screen whenever they need to direct their students’ focus back on them - or simply when the projector is not in use. When activated, this special feature dims the lamp power automatically, lowering the total power consumption by 70%.





100% Lamp Power

Attention on the Projection Screen



30% Lamp Power at the Lowest

Attention on the Class Instructor



No Source Detected Mode



The automatic switch to Eco Blank Mode after the projector is turned on for over three minutes without a display source, eliminating unnecessary energy waste and prolonging the life of the projector lamp.





Source Detected
100% Lamp Power





No Source Detected
30% Lamp Power



When inactive, the MX507 keeps power consumption to a minimum with 0.5W standby power, achieving what was once a challenge for earlier projector models. This technological advancement in energy saving certainly helps extend the projector lamp life and lower energy costs.



With the built-in speaker, the MX507 can be used as an audio system when it's on the standby mode. This saves you the trouble as well as the extra budget for getting a separate audio system.





The upper lamp door is designed for IT managers to replace the projector lamp safely and quickly. should the projector lamp go out in the middle of the class, it can be replaced without delaying the class.







To make your teaching job easier, BenQ has added the teaching template function to the MX507. Now, with four different line pattern designs to choose from - Letter Formation, Musical Staff, Worksheet and Coordinate Chart, you can easily write or draw on whiteboards as well as blackboards without the need of drawing lines or charts.







By pressing Quick Intall key on the remote control, installer can quickly access to installation related functions in the OSD menu.





BenQ DLP Projectors are built with enduring enjoyment in mind, ensuring razor-sharp clarity, ultra-readability and true-to-life color for years to come. We use leading-edge DLP Technology to reflect pure light from millions of micro mirrors on a DMD chip through our advanced color wheels. Since the mirrors are colorless and protected within a nearly-sealed engine, BenQ DLP Projectors have no aging problems and are virtually immune to image decay, consistently delivering picture excellence time and time again. In fact, after 2,000 hours of intense usage, inserting a new bulb produces image quality comparable to a brand-new projector.



Non-DLP Projector





Original Color - After 2000 Hours of Use - After New Lamp Installed







Original Color - After 2000 Hours of Use - After New Lamp Installed



DLP Technology also affords a filter-free engine design for carefree confidence in long-lasting image quality and reduced total cost of ownership. BenQ’s SmartEco™ Technology further boosts contrast performance and image quality endurance while saving up to 70% on lamp power consumption.



Enabling a 96% fill factor, DLP Technology supplies pixel circuitry behind the pixel, thereby eliminating the thick dark bezels around individual pixels, which diminish color and detail. A higher fill factor and less black border translate to noticeably purer, more intense color and smoother image quality.



BenQ DLP Projectors also feature high contrast ratios for flawless rendering of small text, fine lines, and dark scene details. Blacks are deeper and overall image quality is more focused and clean. Your presentations will be easily readable and highly effective, even from the back row of a well-lit venue.





ecoFACTS Label



ecoFACTS can tell you how eco-friendly BenQ products are!



Development of eco-friendly products, BenQ doesn't just want to comply with green regulations passively, but also to actively develop eco-friendly products!



ecoFACTS declares BenQ's greatest efforts on the replacement of hazardous substances, material selection, packaging design, energy-saving design and other aspects of the products.





Projection System	DLP
Native Resolution	XGA (1024 x 768)
Brightness*	3200 lumens
Contrast Ratio	13000:1
Display Color	1.07 Billion Colors
Lens	F=2.56-2.68, f=22.04-24.14mm
Aspect Ratio	Native 4:3 (5 aspect ratio selectable)
Throw Ratio	1.96-2.15 (78" @ 3.1m)
Image Size (Diagonal)	60"-180"/ 300' (Clear Focus/ Maximum)
Zoom Ratio	1.1:1 (Powered)
Keystone Adjustment	1D, Vertical +/- 40 degrees
Projection Offset	120% 5%
Resolution Support	VGA (640 x 480) to UXGA (1600 x 1200)
Horizontal Frequency	15K-102KHz
Vertical Scan Rate	23-120Hz
Interface	Computer In (D-sub 15pin)x 2 (Share with component) Monitor Out (D-sub 15pin)x 1 Composite Video In (RCA)x 1 S-Video In (Mini DIN 4pin)x 1 Audio In (Mini Jack)x 1 Audio Out (Mini Jack)x 1 Speaker2W x 1 USB (Type mini B)x 1 (Download & Page/down) RS232 (DB-9pin)x 1 IR Receiverx 1 (Front)
Dimensions(W x H x D)	283 x 95 x 222mm (include feet) 283 x 88.7 x 222mm (exclude feet)
HDTV Compatibility	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Video Compatibility	NTSC, PAL, SECAM
Weight	1.8kg
Audible Noise	33/ 28 dBA (Normal/ Economic mode)
Power Supply	AC100 to 240V, 50 to 60Hz
Power Consumption	Normal 270W, Eco 220W, Standby < 0.5W
On-Screen Display Languages	Arabic/ Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/ Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/ Russian/ Simplified Chinese/ Spanish/ Swedish/ Turkish/ Thai/ Traditional Chinese (28 Languages)
Picture Modes	Dynamic/ Presentation/ sRGB/ Cinema/ User 1/ User 2
Accessories (Standard)	Remote Control w/ Battery Power Cord (by region) Quick Start Guide Warranty Card (by region) VGA (D-sub 15pin) Cable
Accessories (Optional)	Spare Lamp Kit Ceilling Mount 3D Glasses Carry Bag
3D Support and Compatibility	Frame Sequential: Up to 720p 60Hx (Video), Up to WXGA 120Hz (PC Timing) Side by Side: Up to 1680 x 1050 60Hz (PC Timing) Top Bottom: Up to 1680 x 1050 60Hz (PC Timing)
