SENSOR SECTION |
SENSOR FOR MAIN CAMERA |
Image Sensor |
1/2.3-inch BSI MOS Sensor |
Total Pixels |
18.91 megapixels |
Effective Pixels [Motion Image] |
4K: 8.29 megapixels [16:9], Full-HD: 6.10 megapixels [16:9] (Level Shot Function OFF or Normal) |
Effective Pixels [Still Image] |
7.00 megapixels [3:2] |
Effective Pixels [Still Image] |
8.29 megapixels [16:9] |
Effective Pixels [Still Image] |
6.22 megapixels [4:3] |
SENSOR FOR SUB CAMERA |
Image Sensor |
– |
Total Pixels |
– |
LENS SECTION |
LENS FOR MAIN CAMERA |
F Value |
F1.8 (WIDE) / F3.6 (TELE) |
Optical Zoom |
20x |
Focal Length |
4.08 – 81.6 mm |
35 mm Film Camera Equivalent [Motion Image (16:9)] |
4K: 30.8 – 626 mm (Level Shot Function OFF), Full-HD: 37.0 – 752 mm (Level Shot Function OFF or Normal) |
35 mm Film Camera Equivalent [Still Image] |
34.5 – 690.3 mm [3:2] |
35 mm Film Camera Equivalent [Still Image] |
30.8 – 626 mm [16:9] |
35 mm Film Camera Equivalent [Still Image] |
37.6 – 752.8 mm [4:3] |
Filter Diameter |
49 mm |
Lens Brand |
Leica Dicomar Lens |
LENS FOR SUB CAMERA |
F Value |
– |
Focal Length |
– |
35 mm Film Camera Equivalent [Motion Image] |
– |
CAMERA SECTION |
Standard Illumination |
1400 lx |
Minimum Illumination |
2 lx (Scene Mode Low Light 1/25), 1 lx (Night Mode (Color)), 0 lx (Night Mode (IR)) |
Focus |
Auto / Manual |
Zoom |
Intelligent Zoom OFF |
20x |
Intelligent Zoom ON |
4K: 25x, Full-HD: 40x |
Digital Zoom |
60x / 1500x (The maximum value of zoom magnification can be set in two patterns) |
White Balance |
Auto / White Set / Sunny / Cloudy / Indoor1 / Indoor2 |
Shutter Speed |
Motion Image |
Auto Slow Shutter ON : 1/25 – 1/8000 (50p / 50i / 25p), 1/24 – 1/8000 (24p) |
Motion Image |
Auto Slow Shutter OFF : 1/50 – 1/8000 (50p / 50i / 25p), 1/48 – 1/8000 (24p) |
Still Image |
1/2 – 1/2000 |
Iris |
Auto / Manual |
Image Stabilizer |
HYBRID O.I.S.+ with Active Mode, O.I.S. Lock, Level Shot Function (Strong mode: 2K only) |
HDR Movie (Except 4K Mode) |
Yes |
Creative Control (Except 4K Mode) |
Miniature Effect, Silent Movie, 8mm Movie, Time Lapse Rec |
RECORDING SECTION |
Recording Media |
SD/SDHC/SDXC Memory Card |
Recording Format |
[AVCHD] AVCHD Progressive |
Recording Format |
[iFrame / MP4] MP4 |
Compression Method |
MPEG-4 AVC/H.264 |
Recording/ Playback Mode |
AVCHD |
1080/50p (28Mbps / VBR), (1920 x 1080/50p) |
AVCHD |
PH (24Mbps / VBR), (1920 x 1080/50i) |
AVCHD |
HA (17Mbps / VBR), (1920 x 1080/50i) |
AVCHD |
HG (13Mbps / VBR), (1920 x 1080/50i) |
AVCHD |
HE (5Mbps / VBR), (1920 x 1080/50i) |
MP4 |
2160p/25p(72M) (72Mbps / VBR), (3840 x 2160) |
MP4 |
2160p/24p(72M) (72Mbps / VBR), (3840 x 2160) |
MP4 |
1080p/50p(50M) (50Mbps / VBR), (1920 x 1080) |
MP4 |
1080p/50p(28M) (28Mbps / VBR), (1920 x 1080) |
MP4 |
1080p/24p(50M) (50Mbps / VBR), (1920 x 1080) |
MP4 |
720p/25p(9M) (9Mbps / VBR), (1280 x 720) |
iFrame |
960 x 540/25p (28Mbps / VBR) |
Actual Recordable Time with Supplied Battery |
Approx. 45 min (4K MP4) |
Actual Recordable Time with Supplied Battery |
Approx. 55 min (50p mode) |
Actual Recordable Time with Supplied Battery |
Approx. 55 min (PH mode) |
Actual Recordable Time with Supplied Battery |
Approx. 55 min (HA mode) |
Actual Recordable Time with Supplied Battery |
Approx. 55 min (HG mode) |
Actual Recordable Time with Supplied Battery |
Approx. 55 min (HE mode) |
Actual Recordable Time with Supplied Battery |
Approx. 50 min (2160p/24p) |
Actual Recordable Time with Supplied Battery |
Approx. 1 h 0 min (1080p/24p) |
Actual Recordable Time with Supplied Battery |
Approx. 50 min (MP4 50M) |
Actual Recordable Time with Supplied Battery |
Approx. 55 min (MP4 28M) |
Actual Recordable Time with Supplied Battery |
Approx.1 h 0 min (MP4 720p) |
Actual Recordable Time with Supplied Battery |
Approx. 1 h 0 min (iFrame) |
Thumbnail Display |
20 thumbnails/page, 9 thumbnails/page, 1 thumbnail/page |
Audio Recording System |
AVCHD: Dolby Digital (5.1ch / 2ch) |
Audio Recording System |
iFrame, MP4: AAC (2ch) |
Microphone |
5.1ch Surround, Zoom, Focus and Stereo Microphone |
Speaker |
Dynamic type |
STILL IMAGE SECTION |
Recording Format |
JPEG (DCF/Exif2.2) |
Recording Image Size |
Still Image |
[16:9] 25.9megapixels (6784 x 3816), 14 megapixels (4992 x 2808), 2.1 megapixels (1920 x 1080) |
Still Image |
[3:2] 20 megapixels (5472 x 3648), 10.6 megapixels (3984 x 2656), 2.0 megapixels (1728 x 1152) |
Still Image |
[4:3] 20.4 megapixels (5216 x 3912), 10.9 megapixels (3808 x 2856), 0.3 megapixels (640 x 480) |
Simultaneous Recording |
4K MP4: [16:9] 20.4 megapixels (6016 x 3384), 8.3 megapixels (3840 x 2160) |
Simultaneous Recording |
Other than 4K MP4: [16:9] 14.0 megapixels (4992 x 2808), 2.1 megapixels (1920 x 1080) |
Flash |
– |
GENERAL SECTION |
Power Supply |
3.6V (Battery) / 5.0V (AC Adaptor) |
Power Consumption |
Max. 7.1W (Recording) / Max. 7.7W (Charging) |
Dimensions (W x H x D) |
Approx. 65 x 73 x 139 mm (2.559 x 2.874 x 5.472 inch) |
Weight (w/o battery and SD card) |
Approx. 351g (0.774 lb) |
LCD Monitor |
3.0-inch Wide LCD monitor (460,800 dots) |
Touch Panel |
Yes |
View Finder |
– |
Manual Ring / Dial |
Yes (Dial) |
Interface |
AV |
Yes |
HDMI |
Yes (micro) |
Microphones (stereo mini) |
Yes |
Headphone (stereo mini) |
Yes |
USB |
2.0 Hi-Speed |
USB Charge |
Yes |
LED Video Light |
Yes |
Accessory Shoe |
Yes (cold) |
Lens Cover |
Yes (Auto) |
On-Screen Display Language |
English, Chinese Traditional, Thai, Arabian, Persian, Hindi, Chinese Simplified |
Wi-Fi |
Standard |
IEEE 802.11b/g/n |
Frequency |
2.4GHz band |
NFC |
– |
STANDARD ACCESSORY |
AC Adaptor |
Yes |
AC Cable |
– |
DC Cable |
Yes (USB Type) |
Rechargeable Battery Pack |
Yes (1,940mAh) |
Battery Charger |
– |
IR Remote |
– |
HDMI Cable |
Yes (micro) |
AV Multi Cable |
– |
AV Cable |
– |
Shoe adaptor |
Yes |
Lens Hood |
Yes |
USB Cable |
Yes |
Editing Software |
HD Writer AE 5.3 (Download) |
