All stock codes associated to this product
326L7105A07, QK2200, Q-K2200
Features
NVIDIA® CUDA® Architecture
Parallel-computing architecture that tightly integrates advanced
visualization and compute features to significantly accelerate professional
workflows.
NVIDIA® Parallel DataCache™
Supports a true cache hierarchy combined with on-chip shared memory. L1 and
L2 caches drive exception throughput, accelerating features such as real-time
ray tracing, physics, and texture filtering.
Bindless Textures
Dramatically increases the number of unique textures available to shaders at
run-time, enabling vastly more different materials and richer texture detail in
scenes.
Remote Workstation Application Acceleration
Remotely interact with professional GPU-accelerated applications through
software such as Quadro Experience, Microsoft RDP, Splashtop, and HP Remote
Graphics Software.
NVIDIA® FXAA and TXAA
Reduces visible aliasing and delivers higher image quality without the
performance hit by harnessing the power of the GPU's CUDA cores and new
film-style AA techniques.
16K Texture and Render Processing
Provides the ability to texture from and render to 16K x 16K surfaces.
Beneficial for applications that demand the highest resolution and quality image
processing.
DisplayPort 1.2 Support (with Audio)
Compact and secure DisplayPort 1.2 connectors support multi-stream
technology, stream cloning and ultra-high-resolution panels (up to 4096 x 2160 @
60Hz ). This enables maximum range, resolution, refresh rate, and color depth
designed to support the latest display technologies.
Specifications
CUDA parallel
processing cores |
640 |
Frame Buffer
Memory |
4 GB
GDDR5 |
Memory
Interface |
128-bit |
Memory
Bandwidth |
80 GB/s |
Max Power
Consumption |
60 W |
Graphics
Bus |
PCI Express 2.0
x16 |
Display
Connectors |
DVI-I (1), DP 1.2
(2) |
Form
Factor |
4.376 H x 7.97 L Single
Slot |
Thermal
Solution |
Active |
NVIDIA 3D Vision and
3D Vision Pro |
Support via USB
connection to 3D Vision
Hub |
