All stock codes associated to this product
GVN1070WF2OC8GD, GV-N1070WF2OC-8GD, VCGVN1070WF2OC8GD, VCGV-N1070WF2OC-8GD, 4719331323363, 4719331302528
The WINDFORCE 2X cooling system features two 90mm fans, 2 pure copper composite heat-pipes, unique blade fan design, heat pipes direct touch technology together delivering an effective heat dissipation capacity for higher performance at lower temperatures.
Unique Blade Fan Design
The airflow is spilt by the triangle fan edge, and guided smoothly through the 3D stripe curve on the fan surface, effectively enhancing the air flow by 23% over traditional fans.
3D Active Fan
The 3D Active Fan provides semi-passive cooling, the fans will remain off when the GPU is under a set loading or temperature for low power gaming. It allows gamers to enjoy gameplay in complete silence when the system is running light or idle.
Composite heat-pipes
The composite heat-pipes combines both thermal conductivity and phase transition for efficiently managing the transfer of heat between two solid interfaces which increases 29% of cooling capacity.
Heat Pipe Direct Touch
The pure copper heat pipes are shaped to maximize the direct contact area to the GPU.
One-click Super overclocking
With a simple click on XTREME Engine utility, gamers can easily tune the card to meet their various gaming requirements without any overclocking knowledge, while saving the hassle of manual adjustment.
Ultra Durable Materials
Engineered with the highest-grade chokes and capacitors, this graphic card delivers outstanding performance and durable system lifespan.
Built for OverClocking with 6+2 power phases
Compared to founders edition, the 6+2 power phases on the card
make the MOSFET working at a lower temperature and provide more stable
voltage output.
Xtreme Engine
Adjust clock speeds, voltage, fan performance, power target, OSD setting can be monitored and tuned in real-time according to your own preference through this intuitive interface.
| Graphics Processing | GeForce® GTX 1070 |
| Core Clock | Boost: 1771 MHz/ Base: 1582 MHz in OC Mode
Boost: 1746 MHz/ Base: 1556 MHz in Gaming Mode |
| Process Technology | 16 nm |
| Memory Clock | 8008 MHz |
| Memory Size | 8 GB |
| Memory Type | GDDR5 |
| Memory Bus | 256 bit |
| Card Bus | PCI-E 3.0 x 16 |
| Output | Dual-link DVI-D *1
HDMI-2.0b*1 (Max Resolution: 4096x2160 @60 Hz)
Display Port-1.4 *3 (Max Resolution: 7680x4320 @60 Hz)
|
| Digital max resolution | 7680x4320 |
| Multi-view | 4 |
| Card size | H=37 L=298 W=131 mm |
| PCB Form | ATX |
| DirectX | 12 |
| OpenGL | 4.5 |
| Recommended PSU | 500W |
| Power Connectors | 8 pin*1 |
