Patented Triple Wing-Blade 0dB Fans
Max Air Flow with 105% More Air Pressure
DirectCU III features triple 0dB fans engineered with a patented wing-blade design that delivers maximum air flow and improved 105% static pressure over the heat sink, while operating at 3X quieter volumes than reference cards. The 0dB fans also let you enjoy games in complete silence and make DirectCU III the coolest and quietest graphics card in the market.
ASUS FanConnect
30% Cooler and 3X Quieter Performance
When gaming, GPU temperatures are often higher than CPU temps. However, chassis fans usually reference CPU temperatures only, which results in inefficient cooling of the system. For optimal thermal performance, ROG Strix graphics cards feature two 4-pin GPU-controlled headers that can be connected to system fans for targeted cooling.
Auto-Extreme Technology
Industry-only 100% Automated Production Process
All ASUS graphics cards are now produced using Auto-Extreme Technology, an industry-exclusive, 100% automated production process that incorporates premium materials to set a new standard of quality. Auto-Extreme Technology ensures consistent graphics card quality as well as improved performance and longevity. This new manufacturing process is also environmentally friendly, eliminating harsh chemicals and reducing power consumption by 50%.
6+1 Phase Super Alloy Power II
Enhanced Durability and Efficiency
ASUS engineers have integrated premium alloy components into their graphics card designs to reinforce overall reliability. Super Alloy Power II components greatly enhance efficiency, reduce power loss and achieve thermal levels that are approximately 50% cooler than previous designs.
Aura RGB Lighting
Where Style Meets Performance
Featuring Aura RGB Lighting on the shroud, ROG Strix graphics cards are capable of displaying millions of colors and six different effects for a personalized gaming system.
VR-friendly HDMI Ports
Enjoy Immersive Virtual Reality Experience
ROG Strix graphics cards have two HDMI ports for connecting a VR device and display at the same time, so you can enjoy immersive virtual reality experiences anytime without having to swap cables.
Enjoy the Flawless and Complete Gameplay
The Best Combo for Ultra-smooth Gaming
NVIDIA G-SYNC synchronizes the ROG Swift gaming monitor's refresh rate to the GPU in your GeForce GTX-powered PC, eliminating screen tearing and minimizing display stutter and input lag. With ROG Strix gaming graphics cards and ROG Swift gaming monitors, scenes appear instantly, objects look sharper, and gameplay is super smooth, giving you a stunning visual experience and a serious competitive edge.
Gaming Booster
One-click Performance Up
Visual effects:
Boost your performance by turning off windows visual effects.
System Services:
Automatically or manually turn off windows services or process.
Memory Defragmentation:
Re-arrange & free your system memory without closing any processes.
Specifications
- Graphics Engine
NVIDIA GeForce GTX 1060
- Bus Standard
PCI Express 3.0
- OpenGL
OpenGL®4.5
- Video Memory
GDDR5 6GB
- Engine Clock
OC Mode - GPU Boost Clock : 1746 MHz , GPU Base Clock : 1531 MHz
Gaming Mode (Default) - GPU Boost Clock : 1708 MHz , GPU Base Clock : 1506 MHz
*Retail goods are with default Gaming Mode, OC Mode can be adjusted with one click on GPU Tweak II
- CUDA Core
1280
- Memory Clock
8008 MHz ( DDR2 )
- Memory Interface
192-bit
- Resolution
Digital Max Resolution:7680x4320
- Interface
DVI Output : Yes x 1 (Native) (DVI-D)
HDMI Output : Yes x 2 (Native) (HDMI 2.0)
Display Port : Yes x 2 (Native) (Regular DP)
HDCP Support : Yes
- Accessories
2 x ROG Velcro Hook & Loop
- Software
ASUS GPU Tweak II & Driver
- Dimensions
11.73 " x 5.28 " x 1.57 " Inch
29.8 x 13.4 x4 Centimeter
- Note
.
To have the best cooling performance, ASUS STRIX-GTX1060 extends the
fansink to 2 slots. Please double check you Chassis and Motherboard
dimension prior to purchase to make sure it fits in your system!
.
Note that the actual boost clock will vary depending on actual system
conditions. For more information, please visit https://www.geforce.com/
