All stock codes associated to this product
GPG750H, GP-G750H, 4719331548919, 4719331549091, 4719331548865
- Modular Design
- High quality 100% Japanese electrolytic capacitors
- 140mm smart control fan
- 80 Plus Gold certified
- Single +12V rail
- Supports NVIDIA SLI / AMD CROSSFIRE
- 2 years warranty (Adjusted according to different regions)
Modular Design
The black flat cables are modular. Installing only the cables you need to increase the airflow and to improve the chassis thermal performance.
High Quality 100% Japanese Electrolytic Capacitors
All electrolytic capacitors are high quality Japanese electrolytic capacitors, to produce the efficient performance and to ensure the longer reliability.
140mm Smart Control Fan
140mm cooling fan with smart control system optimizes the noise reduction and the performance. The fan speed is adjusted according to the automatic power detection. The ball bearing fan provides longer and more stable life time.
80 Plus Gold Certified
80 Plus certified ensures the better power efficiency. Less power waste reduces the heat and fan noise.
Single +12V Rail
Single +12V rail provides the best power output, stability and compatibility for the hardware. And it is the best design for overclocking.
| Model | G750H |
| Type | Intel Form Factor ATX 12V v2.31 |
| PFC | Active PFC (>0.9 typical) |
| Input Voltage | 100-240 Vac (full range) |
| Input Current | 10A |
| Input Frequency | 47-63 Hz |
| Output Capacity | 750W |
| Dimension | D160 x W150 x H86mm |
| Fan Type | 140mm Double ball bearing fan |
| Efficiency | 90% at typical load |
| MTBF | >100,000 hours |
| Protection | OVP/OPP/SCP/UVP |
| Regulatory | CE/BSMI/EAC/TUV/FCC/CCC/RCM |
| Connectors | MB 20+4 Pin x1
CPU 4+4 Pin x1
PCI-e 6+2 Pin x4
SATA x7
4Pin Peripheral x3
4Pin Floopy x1
|
| Cable Type | Black Flat Cables |
