AXIS 4 Channel Class D Amplifier - 800W
  • 4 x 75W RMS @4 Ohms, 4 x 115W RMS @2 Ohms, 2 x 240W RMS Bridged @4 Ohms, 90dB SNR, Include Remote Rear Volume Control

IMG 1 of 1
No Longer Available
Part Number:
410410
(?) Brand:
AXIS
Manuf No:
XT4D
Shipping Weight:
5 KG (Includes product packaging)
Estimate Shipping
Details Files Images & Video
All stock codes associated to this product
XT4D, 9321886012576

Overview

The XT4D is a powerful, 4 Channel Class D Digital Amplifier. Engineered with a compact & robust aluminium chassis and packing a huge 800 Watt Max Power, enjoy loud & crystal clear sound reproduction in a range of modes: Single, 2 CH Bridged, Tri-Mode or Monoblock.

Features

  • Compact Chassis
  • Robust Aluminium Construction
  • 4 x 75W RMS Power

Specifications

  • Max Power: 800W (28.4V) (1 channel mode)
  • Output Power @ 14.4V 4Ohm, 1% THD: 4 x 75W RMS@ 14.4V 2Ohm, 1% THD: 4 x 115W RMS@ 14.4V 4Ohm, 1% THD: 2 x 240W RMS
  • THD Continuous @ 4Ohm/1KHz: 0.2%
  • Efficiency @ 4Ohm/1000Hz: 85%
  • S/N Ratio @ 4Ohm/1KHz: 90dB
  • High/Low Level Input Conversion
  • Input Sensitivity: 0.2 - 8V
  • Dampening Factor @4Ohm: 105
  • Low Pass Crossover: 50 - 500Hz
  • Hi Pass Crossover: 50 - 500Hz
  • Bass Boost Gain: 0 - 12dB @ 45Hz
  • 2 Ohm Stable
  • Power Supply: 8 - 16V DC
  • Fuse Rating: 1 x 30A
  • Dimensions: 170 x 204 x 51mm (Chassis) 170 x 244 x 51mm (Including Terminals)
  • Weight: 2.21 kg

Included

  • Rear Channel Remote Volume Controller
  • RCA Fly Leads for High Level Input
  • Installation Accessories



No additional files, specification sheets, guides or documentation found for product.

Warranty: 12 Month Return To Base

Full manufacturers warranty details are available at the manufacturers web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.
