All stock codes associated to this product
AD4S2133W8G15R, AD4S2133W8G15-R
Description
DDR4 offers multiple advantages over previous DRAM generations, and ADATA
provides the highest quality and the fastest performance. Our Premier SO-DIMM
DDR4 modules for notebooks arrive in convenient 4GB and 8GB for instant upgrades
on any compatible notebook. They deliver faster data transfers than DDR3,
coupled with lower energy consumption that reduces heat and extends battery
life. Our DDR4 is also optimized to unlock the power of the newest Intel
processors.
Extra Fast and Ultra Efficient
ADATA DDR4 modules for notebooks realize new generation advantages in highly
reliable and cost-effective products. DDR4 brings higher performance thanks to
faster frequencies compared to DDR3, going up to 2133MHz. It does this while
operating at a low 1.2V, which is 20% less than DDR3 in terms of energy
consumption. DDR4 is therefore more performance and greater efficiency in
one.
Specifications and Compatibility Info
- Module capacity: 4GB / 8GB
- Full RoHS and JEDEC compliance assured by ADATA
- Complete support for the latest Intel processors (Skylake/Haswell-E and
beyond)
Lifetime Warranty
All ADATA memory modules are produced and tested by a rigorous quality
control process for rapid computing and stable operation. In addition, ADATA
memory modules provide customers a lifetime warranty for maximum assurance with
excellent service.
Specifications
|
Module
Type |
SO-DIMM |
|
Form
Factor |
standard 1.18"
height |
|
Memory
Type |
DDR4 |
|
Standard |
JEDEC |
|
Interface |
260-pin |
|
Capacity |
8GB |
|
Speed |
2133MHz |
|
Power
Supply |
VDD & VDDQ =
1.2V0.06V |
|
DRAM Activation
Power Supply |
VPP= 2.5V (+0.25V /
-0.125V) |
|
DRAM
Spec/VCC |
DDR4 STD
1.2V |
|
Operation
Temperature |
0C to
85C |
|
Warranty |
limited lifetime
warranty |
