Overview
Well-built ATX gaming board loaded with gaming-optimized
features
- LGA1151 socket for 6th-gen Intel® Core™ i7 / Core i5 / Core i3, Pentium®
and Celeron Processors
- Dual DDR4 2133 support
- SupremeFX: Flawless audio that makes you part of the game
- Sonic Radar ll: Scan and detect your enemies to dominate
- Intel Gigabit Ethernet, LANGuard and GameFirst III: Top-speed protected
networking
- RAMCache: Speed up your game loads
- Gamer's Guardian: Highly-durable components and smart DIY features
- USB 3.1 Type-A/C and M.2: Ultra-speedy transfers for faster gaming
FLAWLESS AUDIO THAT MAKES YOU PART OF THE GAME!
Be the best on the battlefield with H170 Pro Gaming's truly immersive
SupremeFX audio and experience sound so alive with realism that it hands you the
vital competitive edge needed to win. With near-lossless delivery and exclusive
Sonic Radar II technology to pinpoint battlefield enemies before they spot you,
SupremeFX sounds stupendous and puts both your ears and frags in front of
everyone else!
SupremeFX
Shielded audio, superior sound
ASUS-exclusive SupremeFX technology delivers high-fidelity, near-lossless
audio no matter how frantic your game becomes. The purity and stability of the
remarkable 115dB signal-to-noise ratio (SNR) is assured, with a shielded design,
electromagnetic-interference (EMI) cover and voltage-protected 5V power supply.
Supreme FX's superior components, including the trusted Realtek ALC1150 codec,
maximize acoustic performance and eliminate interference – so you hear only the
very best from your gaming headset or speakers!
Illuminated red line shielding
Banish analog interference and enjoy eye-catching, customizable lighting
effects.
EMI cover
Effective shielding against electromagnetic interference preserves the
integrity of audio signals for the best quality.
300O-headphone amplifier
Drive some of the very best headphones available for exceptional gaming-audio
and music-listening experiences.
Premium Nichicon® audio capacitors
Fine-quality Japanese-made components that produce a warmer, natural sound
with exceptional clarity and fidelity.
Sonic Radar II
Scan and detect to dominate!
Sonic Radar II displays a stealthy overlay that shows what your opponents and
teammates are up to on the battlefield, all managed via a simple control panel
and customizable game list. See the direction and origin of key in-game sounds,
and practice your enemy-pinpointing skill, plus Audio Enhancement technology
clarifies every last sound — so you hear the distant sound of enemy footsteps
and become the hunter, not the hunted!
TOP-SPEED PROTECTED NETWORKING
Only the quickest shot survive, so H170 Pro Gaming banishes lag — letting you
annihilate your foes as fast as your trigger finger! Our engineers pack in only
the best networking technology, including tournament-level Intel® Gigabit
Ethernet and ASUS-exclusive LANGuard and GameFirst III to keep your connection
fast, so always fire first and watch your enemies fall.
Intel Gigabit Ethernet
More throughput, less CPU usage and great gaming experiences
Featuring the very latest Intel Ethernet (I219V) for faster, smoother gaming
— always. Intel's LAN has the serious double advantage of reducing CPU overhead
and offering exceptionally high TCP and UDP throughput. This significantly
reduces the processor's workload, so there's more power for your game and your
gameplay.
LANGuard
Pumped-up throughput. Best surge protection
ASUS LANGuard is hardware-level networking protection that employs
signal-coupling technology and premium anti-EMI surface-mounted capacitors for
rock-solid gaming connections and better throughout for online play, plus
electrostatically-guarded and surge-protected components for greater tolerance
to static electricity and improved protection against surges.
GameFirst III
Game faster, score higher
Victory and defeat are separated by just milliseconds, so exclusive GameFirst
III prioritizes game-related packets and allocates more bandwidth to games,
eliminating laggy gameplay, streaming stutters and file-sharing slowdown —
ensuring you're always the frontrunner. Choose from Optimization, Game, Media
Streaming or File Sharing presets and watch your network fly!
PERFORMANCE LEVEL UP
Maxed-out performance means maximum gaming thrills, and with exclusive AI
Suite 3's dashboard-style control panel you'll fine-tune almost every aspect of
your H170 Pro Gaming-based system. Get the best balance between performance,
cooling, stability, efficiency and aesthetics — all via a simple and intuitive
interface.
GPU Boost
Exclusive ASUS GPU Boost technology lets you accelerate H170 Pro Gaming's
integrated GPU (iGPU) for extreme graphics performance safely and easily via a
user-friendly interface – it's a free iGPU level-up!
Fan Xpert 3
Via five 4/3 pin (PWM/DC) combo fan connectors and five onboard thermal
sensors, Fan Xpert 3 makes sure every fan achieves the best balance of cooling
performance and low noise. H170 Pro gaming also has a fan-extension (EXT) header
for quick-and-easy fan upgrades.
USB 3.1 Boost
An exclusive utility that automatically accelerates USB 3.1 for sequential
read/write speeds of up to 854.6/863.9MB/s. * It requires to update USB 3.1
Boost to V1.08.02 or later version
LED Control
Customizing the audio and marque LEDs is easy: just flip the switches and
pick the radio buttons that match your style and gaming mood!
Award-winning BIOS design
The smoothest, slickest mouse-controlled graphical BIOS has been improved to
make it even more appealing. Whether you're a PC novice or a seasoned
overclocker, the EZ and Advanced Modes help you find your way. In EZ Mode you
can get set up very quickly, applying the date and time, fan profiles and Intel
Extreme Memory Profile (XMP) memory profiles. Switch to Advanced Mode to set up
favorites and shortcuts, record and review recent changes with Last Modified or
make notes in Quick Notes.
CrashFree BIOS 3
Never again worry about corrupted BIOS, as CrashFree BIOS 3 lets you restore
a PC to working order even when it won't boot!
EZ Flash 3
Update the latest BIOS via the internet, and from within the BIOS.
RAMCache
Uniquely-intelligent technology that effectively caches an entire storage
device so that favorite games and apps launch at breakneck speeds, getting to
work the moment it's activated. RAMCache turns milliseconds into microseconds to
boost game-load times to stratospheric levels!
GAMER'S GUARDIAN FOR REAL-WORLD PROTECTION
Protect your back in the game and let H170 Pro Gaming protect all sides in
the real world! Motherboard self-protection with loads of brilliant defenses,
including our unique smart DIY features ensures long-term gaming is in your
future.
Digi+ VRM
Digi+ VRM voltage-regulator module (VRM) is one of the finest in the
industry, ensuring ultra-smooth and ultra-clean power delivery to the CPU at all
times!
DRAM overcurrent protection
All connection ports and DRAM are protected against overcurrent and
short-circuit damage by onboard resettable fuses, extending your motherboard's
life.
Highly durable components
Fine-quality, super-tough components are our watchwords. We fit only superior
chokes, plus durable capacitors engineered to resist extreme temperature
variations of between -55°C and 105°C —110% better than the industry
standard.
Stainless steel back I/O
Crafted from chromium-plated, corrosion-resistant stainless steel, the
input/output (I/O) panel is three times longer than ordinary panels!
Q-shield
0 pain! Protect your hands from nicks and cuts
Q-slot
1 clip to swap or secure your graphics card.
Q-DIMM
1 -sided clips mean handling memory modules is a cinch — super simple and
super secure.
Q-LED
4 LEDs indicate problems with the CPU, memory, graphics card or boot device
for quick diagnosis.
ESD Guards
2X-greater ESD protection for extended component lifespan
Electrostatic discharge (ESD) could mean game over for your rig, so H170 Pro
Gaming is protected by ESD Guards to actively prevent ESD — ensuring longer
component lifespan and providing system resilience that's two times greater than
industry standards. Game on!
BUILT FOR GAMING
H170 Pro Gaming is built for play, shaped by professional gamers and tested
for gaming perfection strong enough storm through the industry's most punishing
labs workouts. We engineer and test for the finest quality, longevity,
performance, stability and compatibility. Our world-class engineers are
themselves avid gamers, and combine their own passion with the skills and
demands of some of the planet's best players to create innovative gaming
features everyone will crave. With H170 Pro Gaming you do more than just play
you'll experience gaming on the edge of reality.
THE POWER OF INTEL!
Intel H170 Express Chipset
Intel H170 Express is a single-chipset design that supports 6th-generation
Intel LGA1151 Core i7/Core i5/Core i3/Pentium/Celeron processors. It provides
improved performance by utilizing serial point-to-point links, allowing
increased bandwidth and stability. Additionally, H170 provides a maximum eight
USB 3.0 ports, six SATA 6Gbit/s ports, 32Gbit/s M.2 and PCIe 3.0 lane speed
support for faster data retrieval. Intel H170 Express also supports
integrated-graphics (iGPU) functions, so you'll enjoy the very latest Intel
integrated graphics performance.
Ready for 6th-generation Intel LGA1151 Core i7/Core i5/Core
i3/Pentium/Celeron processors
This motherboard supports 6th-generation Intel Core i7/i5/i3/Pentium/Celeron
processors in the LGA1151 package, with graphics, memory and PCI Express
controllers integrated to support onboard graphics output with dedicated
chipsets, two-channel (4-DIMM) DDR4 memory and 16 PCI Express 3.0/2.0 lanes for
great graphics performance.
Specifications
|
CPU
|
Intel Socket 1151 for
6th Generation Core i7/Core i5/Core i3/Pentium/Celeron
Processors |
|
Supports Intel 14 nm
CPU |
|
Supports Intel Turbo
Boost Technology 2.0 |
|
* The Intel Turbo Boost
Technology 2.0 support depends on the CPU types. |
|
* Refer
to www.asus.com for CPU support list |
|
|
|
Chipset
|
Intel
H170 |
|
|
|
Memory
|
4 x DIMM, Max. 64GB,
DDR4 2133 MHz Memory |
|
Dual Channel Memory
Architecture |
|
Supports Intel Extreme
Memory Profile (XMP) |
|
* Hyper DIMM support is
subject to the physical characteristics of individual
CPUs. |
|
* Refer
to www.asus.com for the Memory QVL (Qualified Vendors
Lists). |
|
|
|
Graphic
|
Integrated Graphics
Processor- Intel HD Graphics support |
|
Multi-VGA output
support : HDMI/DVI-D/RGB/DisplayPort ports |
|
- Supports HDMI with
max. resolution 4096 x 2160 @ 24 Hz |
|
- Supports DVI-D with
max. resolution 1920 x 1200 @ 60 Hz |
|
- Supports RGB with
max. resolution 1920 x 1200 @ 60 Hz |
|
- Supports DisplayPort
with max. resolution 4096 x 2304 @ 60 Hz |
|
Maximum shared memory
of 512 MB |
|
Supports Intel InTru
3D, Quick Sync Video, Clear Video HD Technology,
Insider |
|
|
|
Multi-GPU Support
|
Supports AMD Quad-GPU
CrossFireX Technology |
|
Expansion Slots
|
|
1 x PCIe 3.0/2.0
x16 |
|
1 x PCIe 3.0/2.0 x16
(x4 mode, black) |
|
4 x PCIe 3.0/2.0
x1 |
|
|
|
Storage
|
Intel H170 chipset
: |
|
1 x SATA Express port,
Compatible with 2 x SATA 6.0 Gb/s ports |
|
1 x M.2 Socket 3, with
M Key, type 2242/2260/2280/22110 storage devices support (both SATA &
PCIE mode)*1 |
|
4 x SATA 6Gb/s
port(s) |
|
Support Raid 0, 1, 5,
10 |
|
Supports Intel Smart
Response Technology*2 |
|
|
|
LAN
|
Intel I219V, 1 x
Gigabit LAN Controller(s), GameFirst technology |
|
Anti-surge
LANGuard |
|
|
|
Audio
|
SupremeFX 8-Channel
High Definition Audio CODEC |
|
- Supports :
Jack-detection, Multi-streaming, Front Panel MIC
Jack-retasking |
|
- High quality 115 dB
SNR stereo playback output |
|
Audio Feature
: |
|
- SupremeFX Shielding
Technology |
|
- Optical S/PDIF out
port(s) at back panel |
|
- Sonic Radar
II |
|
|
|
USB Ports
|
ASMedia USB 3.1
controller : |
|
1 x USB 3.1 port(s) (1
at back panel, , Type-A) |
|
ASMedia USB 3.1
controller : |
|
1 x USB 3.1 port(s) (1
at back panel, , Type-C, Reversible) |
|
Intel H170 chipset
: |
|
6 x USB 3.0/2.0 port(s)
(2 at back panel, , 4 at mid-board) |
|
Intel H170 chipset
: |
|
8 x USB 2.0/1.1 port(s)
(2 at back panel, , 6 at mid-board) |
|
|
|
Special Features
|
Gamer's
Guardian: |
|
- ESD Guards on LAN,
Audio, KBMS and USB3.0/2.0 ports |
|
- DRAM Overcurrent
Protection |
|
- Stainless Steel Back
I/O |
|
- Highly Durable
Components |
|
- DIGI+
VRM |
|
ASUS Exclusive
Features : |
|
- GPU
Boost |
|
- AI Suite
3 |
|
- Ai
Charger+ |
|
- USB 3.1
Boost |
|
- Disk
Unlocker |
|
ASUS Quiet Thermal
Solution : |
|
- Stylish Fanless
Design Heat-sink solution & MOS Heatsink |
|
- ASUS Fan Xpert
3 |
|
ASUS EZ DIY
: |
|
- ASUS CrashFree BIOS
3 |
|
- ASUS EZ Flash
3 |
|
- ASUS UEFI BIOS EZ
Mode |
|
ASUS Q-Design
: |
|
- ASUS
Q-Shield |
|
- ASUS Q-LED (CPU,
DRAM, VGA, Boot Device LED) |
|
- ASUS
Q-Slot |
|
- ASUS
Q-DIMM |
|
Media
Streamer |
|
RAMCache |
|
|
|
Operating System
Support |
Windows 10 ,
64bit |
|
Windows 8.1 ,
64bit |
|
Windows 7 ,
32bit/64bit |
|
|
|
Back I/O Ports
|
1 x PS/2 keyboard/mouse
combo port(s) |
|
1 x
DVI-D |
|
1 x
D-Sub |
|
1 x
DisplayPort |
|
1 x
HDMI |
|
1 x LAN (RJ45)
port(s) |
|
1 x USB 3.1
(black)Type-C |
|
1 x USB 3.1
(red)Type-A |
|
2 x USB
3.0 |
|
2 x USB
2.0 |
|
1 x Optical S/PDIF
out |
|
5 x Audio
jack(s) |
|
|
|
Internal I/O Ports
|
2 x USB 3.0
connector(s) support(s) additional 4 USB 3.0
port(s) |
|
3 x USB 2.0
connector(s) support(s) additional 6 USB 2.0 port(s) |
|
1 x SATA Express
connector: , Compatible with 2 x SATA 6.0 Gb/s ports |
|
1 x M.2 Socket 3 with M
Key design, type 2242/2260/2280/22110 storage devices support (Supports
both SATA & PCIE SSD) |
|
1 x COM port(s)
connector(s) |
|
4 x SATA 6Gb/s
connector(s) |
|
1 x CPU Fan
connector(s) (1 x 4 -pin) |
|
1 x CPU OPT Fan
connector(s) (1 x 4 -pin) |
|
3 x Chassis Fan
connector(s) (3 x 4 -pin) |
|
1 x 24-pin EATX Power
connector(s) |
|
1 x 8-pin ATX 12V Power
connector(s) |
|
1 x Front panel audio
connector(s) (AAFP) |
|
1 x System
panel(s) |
|
1 x Thermal sensor
connector(s) |
|
1 x CPU
OV |
|
1 x Clear CMOS
jumper(s) |
|
1 x 5-pin
EXT_FAN(Extension Fan) connector |
|
1 x ROG extension
(ROG_EXT) header(s) |
|
1 x 14-1 pin TPM
connector |
|
|
|
Accessories
|
User's
manual |
|
I/O
Shield |
|
4 x SATA 6Gb/s
cable(s) |
|
1 x M.2 Screw
Package |
|
1 x Supporting
DVD |
|
1 x 12 in 1 Cable Label
(s) |
|
|
|
BIOS
|
128 Mb Flash ROM, UEFI
AMI BIOS, PnP, DMI 3.0, WfM 2.0, SM BIOS 3.0, ACPI 5.0, Multi-language
BIOS, ASUS EZ Flash 3,CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan
Control, F3 My Favorites, F9 Quick Note, F12 PrintScreen function and ASUS
DRAM SPD (Serial Presence Detect) memory information |
|
|
|
Manageability
|
WfM 2.0, DMI 3.0, WOL
by PME, PXE |
|
|
|
Support Disc
|
Drivers |
|
ASUS
Utilities |
|
ASUS EZ
Update |
|
Anti-virus software
(OEM version) |
|
|
|
Form Factor
|
ATX Form
Factor |
|
12 inch x 9.6 inch (
30.5 cm x 24.4 cm ) |
|
|
|
Note
|
*1:When the M.2 Socket
3 is operating in SATA mode, SATA port 1 will be
disabled. |
|
*2:These functions will
work depending on the CPU
installed. |
