All stock codes associated to this product
55LW340C, 3355145, 8806087735093
Overview
| HD 1,366 x
768 |
| USB
CLONING |
| USB AUTO
PLAYBACK + |
| SELF
DIAGNOSTIC (USB) |
| 2X10W
SPEAKERS |
Features
EXTERNAL SPEAKER OUT
By adding an additional speaker, guests can listen to the TV sound from a
second location in the guest room. Even in the bathroom, guests can hear and
control the TV sound level.
USB AUTO PLAYBACK+
USB Auto Playback+ allows you to create playlists from your favourite media
files* then play on the TV.
*mp4, avi, mov, tp, wma, ts
TIME SCHEDULE
Create your own time schedule for your Commercial TV. Once you set
opening/closing hours and holidays, the TV will turn on/off according to work
schedule.
HOTEL MODE
From channel selection to energy saving features, you can control the TV
settings in all the rooms with Hotel Menu. Prevent misuse by customers, set
volume limits, or reset to default settings on the TV. You are in control of it
all.
LOCK MODE
The Lock Mode blocks external input signals as a useful feature for
preventing misuse of TVs in government facilities and public spaces.
REMOTE DIAGNOSTICS (USB)
Enables service technicians to recognise technical issues in the TV quickly
and easily through a USB device. The TV stores technical issues it encounters
and can output it to a USB device. Service technicians can use the information
to diagnose technical issues remotely.
WELCOME SCREEN/ VIDEO
First impressions are important. Having a warm greeting message with the
Hotel name and its logo on the TV or a customised video in various formats* will
help the guest feel more welcome.
* mp4, avi, mov, tp, wma, ts
MULTI IR
Multi IR function reduces the remote control signal interference between TVs
in multiple dwelling beds. This system will work with the same LG TV model.
IR OUT
IR out allows you to control the commercial LG TV and set top box via RS232
using one IR remote.
Design, features and specifications subject to change without
notice. Screen images simulated and/or dramatised. Some features in videos may
not be available on all models. Please refer to the TECHNICAL SPECIFICATIONS tab
for a complete list of features by model.
Specifications
|
DISPLAY
|
|
|
Screen
Size |
55"
(139cm) |
|
Type |
Edge
LED |
|
Resolution |
1,920 x 1,080
(FHD) |
|
|
|
BROADCASTING SYSTEM
|
|
|
Analogue |
PAL /
SECAM |
|
Digital |
DVB-T2/C/S2 (Varied By
Countries) |
|
|
|
AUDIO
|
|
|
Audio
Output |
10W +
10W |
|
|
|
BASIC COMMERCIAL TV
FEATURES |
|
|
Additional |
Welcome Screen/Video,
Lock Mode, Hotel Mode, Multi-IR Code, USB Cloning, One Channel Map,
External Speaker Out, USB Auto Playback+, Time
Scheduler |
|
|
|
GENERAL FEATURES
|
|
|
Type |
Commercial Lite
TV |
|
Interactive
Protocol |
N/A |
|
HCAP(GEM/FLASH/HTML) |
N/A |
|
Management |
Remote Diagnostics
(USB) |
|
Interactivity |
HTNG /
HDMI-CEC |
|
RJP
Interface |
RS-232C,
HDMI-CEC |
|
Auto Off/ Auto
Sleep |
Yes |
|
Intelligent
Sensor |
N/A |
|
Smart Energy
Saving |
Yes |
|
Anti-theft
System |
Kensington
Lock |
|
|
|
INTERFACE (SIDE)
|
|
|
HDMI
In |
Yes
(1) |
|
USB |
USB 2.0
(1) |
|
Headphone Out (3.5mm
Phone Jack) |
Headphone Out
(1) |
|
|
|
INTERFACE (REAR)
|
|
|
RF In |
Yes
(2) |
|
AV In |
Yes |
|
Component
In |
(Audio,
RCA5) |
|
Optical Audio
Out |
Yes
(1) |
|
RGB In (D-sub
15pin) |
RGB In
(1) |
|
PC Audio
Input |
N/A |
|
RS-232C |
Yes
(1) |
|
HDMI
In |
N/A |
|
LAN |
N/A |
|
Ext SPK
out |
Yes
(1) |
|
|
|
POWER
|
|
|
Voltage,
Hz |
100~240V, 50 / 60
Hz |
|
Typical(Watts) |
90 |
|
Stand-by(Watts) |
0.2 |
|
|
|
STANDARD
(CERTIFICATION) |
|
|
Safety |
AS/NZS 60065, CB
Scheme |
|
EMC |
AS/NZS CISPR,
32-RCM |
|
Energy
Rating |
209kWh/year and 7
stars |
