Overview
GIGABYTE G1 Gaming Series graphics cards are crafted for perfection in
pursuit of the ultimate graphics experience for gaming enthusiasts. Based on the
revolutionary NVIDIA® Pascal™ GPU architecture, G1 gaming graphics card brings
you incredible gaming experience. -Pascal-powered graphics card give you
superior performance and power efficiency -Support up to 8K display @60Hz
-Outstanding performance for Virtual Reality gaming
WINDFORCE 2X Cooling System
The WINDFORCE 2X cooling system features two
90mm unique blade fans, 2 pure copper composite heat-pipes, alternate spinning
fan design, and heat pipes direct touch technology, together delivering an
effective heat dissipation capacity for higher performance at lower
temperatures.
WINDFORCE 2X Cooling System-Fans
Alternate Spinning Fan Design
Optimize air flow by the alternate spinning fans that reduce air turbulence
and effectively dissipate the heat.
Unique Blade Fan Design
The airflow is spilt by the triangle fan edge, and guided smoothly through
the 3D stripe curve on the fan surface, effectively enhancing the air flow by
23% over traditional fans.
3D Active Fan with LED Indicators
The semi-passive fans will remain off when the GPU is under a set loading or
temperature for low power gaming. The LED fan indicator on the top of the
graphics card provides an instant display of the fan status.
WINDFORCE 2X Cooling System-Heat Pipes
Composite heat-pipes
The composite heat-pipes combines both thermal conductivity and phase
transition for efficiently managing the transfer of heat between two solid
interfaces which increases 29% of cooling capacity.
Heat Pipe Direct Touch
The pure copper heat pipes are shaped to maximize the direct contact area to
the GPU.
G1 Outlook
16.8M
Customizable Color Lighting
With
16.8M customizable color options and numerous lighting effects, you could now
choose the right scheme for your gaming rig through XTREME Engine utility.
Stylish Metal Back Plate
The metal back plate offers rigidity and protection to the structure, while
adding a sleek, clean look to the product.
Performance
One-click Super overclocking
With a simple click on XTREME engine utility, gamers can easily tune the card
to meet their various gaming requirements without any overclocking knowledge,
while saving the hassle of manual adjustment.
GPU Gauntlet Sorting
Forged with only the top-notch GPU, the Gigabyte G1 GAMING graphics cards
guarantee higher overclocking capability in terms of excellent power switching,
ensuring the highest performance without compromising system reliability.
G1 Durability
Smart Power LED indicators
Be alert when PCI-E voltage is unstable with the smart power LED indicator.
Ultra Durable Materials
Engineered with the highest-grade chokes and capacitors, this graphic card
delivers outstanding performance and durable system lifespan.
Built for OverClocking with 6+1 power phases
Compared to reference design, the 6+1 power phases on the card make the
MOSFET working at a lower temperature and provide more stable voltage output.
(*reference design 3+1)
Intuitive Utility
Intuitive XTREME Engine Utility
Adjust clock speeds, voltage, fan performance, RGB lighting effect, power
target can be monitored and tuned in real-time according to your own preference
through this intuitive interface. (*The interface and functionality of the
software is subject to each model.)
Specifications:
|
Graphics Processing |
GeForce GTX 1060 |
|
Core Clock |
Boost: 1847 MHz/ Base: 1620 MHz in OC
Mode
Boost: 1809 MHz/ Base: 1594 MHz in
Gaming |
|
Process
Technology |
16 nm |
|
Memory Clock |
8008 MHz |
|
Memory Size |
3
GB |
|
Memory
Type |
GDDR5 |
|
Memory Bus |
192 bit |
|
Card
Bus |
PCI-E 3.0 x 16 |
|
Output |
Dual-link DVI-D x1
HDMIx1 (Max Resolution: 4096x2160@60
Hz)
Display Portx3 (Max Resolution: 7680x4320 @60
Hz) |
|
Digital max
resolution |
7680x4320 |
|
Multi-view |
4 |
|
Card
size |
H=40 L=278 W=114
mm |
|
PCB
Form |
ATX |
|
DirectX |
12 |
|
OpenGL |
4.5 |
|
Recommended
PSU |
400W |
|
Power
Connectors |
8
pin |
