GPU |
AMD
Radeon RX 6500 XT Graphics Card |
|
6nm
GPU |
|
AMD
RDNA 2 Architecture |
|
Engine
Clock |
Boost
Clock: Up to 2825 MHz |
|
Game
Clock: Up to 2685 MHz |
|
Boost
Clock is the maximum frequency achievable on the GPU running bursty
workload. Boost clock achievability, frequency, and sustainabilty will
vary based on several factors, including but not limited to: thermal
conditions and variation in application and
workloads. |
|
Game
Clock is the expected GPU clock when running typical gaming applications,
set to typical TGP(Total Graphics Power). Actual individual game clock
results may vary. |
|
Stream
Processors |
1024 |
|
Infinity
Cache |
16MB |
|
Ray
Accelerators |
16 |
|
Memory
Size/Bus |
4GB
GDDR6 |
|
Memory
Clock |
18
Gbps Effective |
|
Displays |
Maximum
2 Displays |
|
Resolution |
HDMI:
76804320 |
|
DisplayPort1.4:
76804320 |
|
Interface |
PCI-Express
4.0 |
|
Output |
1x
HDMI |
|
1x
DisplayPort |
|
BIOS
Support |
UEFI |
|
Game
Index |
1080P |
|
Sapphire
Features |
Premium
Digital Power Design |
|
Fuse
Protection |
|
Dual-X
Cooling Technology |
|
Intelligent
Fan Control |
|
Precision
Fan Control |
|
Metal
Backplate |
|
TriXX
Supported |
|
TriXX
Boost |
|
AMD
Features |
AMD
RDNA 2 Gaming Architecture |
|
DirectX
12 Ultimate support |
|
AMD
Smart Access Memory |
|
AMD
Infinity Cache |
|
6nm
GPU |
|
PCI
Express 4.0 support |
|
AMD
FreeSync Technology |
|
DisplayPort
1.4 with DSC |
|
HDMI
support |
|
Video
Streaming up to 8K |
|
AMD
Radeon VR Ready Premium |
|
AMD
FidelityFX |
|
AMD
Radeon Image Sharpening |
|
AMD
Radeon Anti-Lag |
|
AMD
Radeon Software |
|
Game
Driver Optimizations |
|
Cooling |
Dual
Fans |
|
Form
Factor |
2
slot, ATX |
|
Dimension:
194(L)X 107(W)X 40(H)mm |
|
Power
Consumption |
130W
(Board Power) |
|
OS |
Linux,
Windows 7*, Windows 10, and Windows 11 64-bit operating system
required |
|
*Does
not support all features including but not limited to Hardware
Raytracing |
|
System
Requirement |
Minimum
400 Watt Power Supply |
|
1
x 6-pin Power Connector. |
|
PCI
Express based PC is required with one X16 lane graphics slot available on
the motherboard. |
|
Minimum
8GB of system memory. 16GB
recommended. |
