| Scan system |
Optical scanning resolution
|
Up to 4800 dpi
|
Hardware scanning resolution
|
Up to 4800 x 9600 dpi
|
Enhanced scanning resolution
|
Unlimited
|
Bit depth
|
48-bit
|
Gray scale levels
|
256
|
Image scaling or enlargement range
|
10 to 2400% in 1% increments
|
Scan speed in preview mode
|
11 sec
|
Scan speed footnote
|
Scan speed tests performed on a HP Media Center PC with 3 GHz, 1 GB of RAM and Microsoft Windows XP Media Center, two USB connections
|
Scan speed (OCR, A4)
|
< 30 sec
|
Maximum scanning size
|
22 x 30 cm
|
| Photo and Smart Features |
Transparency adapter
|
Built-in Transparent Materials Adapter (TMA); four 35 mm slides or five 35 mm negative frames
|
Auto document feeder capacity
|
None
|
Button functions
|
4 buttons (Copy, Scan, Scan to E-mail, Scan to PDF)
|
| Other technical information |
Scan input modes
|
Front-panel scan (reflective scans from the glass, transmissive scans of film materials), Copy, Scan to E-mail, Scan to PDF; HP Photosmart software, Scan picture, Scan document, Scan film, Copy; user application via TWAIN; integrated transparent media adapter (transmissive scans of film materials)
|
Scan file format
|
Microsoft Windows: PDF, PDF searchable, TIFF, TIFF compressed, JPG, BMP, PNG, FPX, GIF, PCX, RTF, TXT, HTML; Macintosh: PDF, TIFF, JPG, FPX, GIF, PICT, RTF, TXT, HTML
|
Compatible operating systems
|
Microsoft Windows 2000, XP Home, XP Professional, XP Professional x64, XP Media Center; Certified for Windows Vista ; OS X v10.4.11, v10.5 or higher
|
Standard connectivity
|
Hi-Speed USB 2.0
|
External I/O ports
|
1 Hi-Speed USB 2.0
|
Minimum system requirements
|
Microsoft Windows XP Home, XP Professional, XP Professional x64, 2000: 500 MHz processor, 128 MB RAM, 450 MB available hard disk space, USB port, CD-ROM drive, 800 x 600 SVGA monitor, 16-bit colour, Microsoft Windows Internet Explorer 6 or higher; Windows Vista, x64: 800 MHz processor, 512 MB RAM, 450 MB available hard disk space, CD-ROM drive, 800 x 600 SVGA monitor, DirectX 9 capable graphics, Microsoft Windows Internet Explorer 7
|
Energy Star certified
|
Yes
|
Dimensions (W x D x H)
|
455 x 305 x 70 mm
|
Weight
|
2.9 kg
|
Electromagnetic compatibility
|
EU (CE certification of conformity), North America (FCC & Canadian EMC declaration), Australia (ACA), New Zealand (ACA), Russia (GOST), Korea (MIC), Taiwan (BSMI), China (CCC)
|
Operating humidity range
|
0 to 90% RH
|
Non-operating humidity
|
0 to 90% RH
|
Recommended humidity operating range
|
15 to 80% RH
|
Operating temperature range
|
10 to 35 C
|
Recommended operating temperature range
|
10 to 35 C
|
Power consumption
|
15 watts maximum
|
Power supply type
|
External power adapter
|
Power requirements
|
North America: input voltage 120 VAC (+/- 10%), 50/60 Hz (+/- 3 Hz); rest of world: 100 to 240 VAC (+/- 10%), 50/60 Hz (+/- 3 Hz)
|
Storage temperature range (Celsius)
|
-40 to 60 C |
|
