Lens construction
|
![](/images/extra/90/e2008091859496.jpg)
|
13 elements in 10 groups (with three ED glass elements, three aspherical lenses, one with Nano Crystal Coat) |
![](/images/extra/90/e2008091859496.jpg)
|
Picture angle
|
![](/images/extra/90/e2008091859496.jpg)
|
84 (maximum 101 when fully shifted) |
![](/images/extra/90/e2008091859496.jpg)
|
Focal-length scale
|
![](/images/extra/90/e2008091859496.jpg)
|
NA |
![](/images/extra/90/e2008091859496.jpg)
|
Number of diaphragm blades
|
![](/images/extra/90/e2008091859496.jpg)
|
9 (rounded) |
![](/images/extra/90/e2008091859496.jpg)
|
Diaphragm
|
![](/images/extra/90/e2008091859496.jpg)
|
Electrically automatic/One-touch preset aperture operation |
![](/images/extra/90/e2008091859496.jpg)
|
Minimum f/stop
|
![](/images/extra/90/e2008091859496.jpg)
|
32 |
![](/images/extra/90/e2008091859496.jpg)
|
Lens movement
|
![](/images/extra/90/e2008091859496.jpg)
|
Shift and tilt movement at right angles (the two operations can be modified for a surcharge, to move in the same [parallel] direction. The shift lock release knob can also be changed for a larger one, but the changed knob may affect mounting the lens to the camera or lens operation.) Maximum shift amount: 11.5mm Maximum tilt amount: 8.5 |
![](/images/extra/90/e2008091859496.jpg)
|
Lens rotation
|
![](/images/extra/90/e2008091859496.jpg)
|
90 right and left (click-stop for each 30 step) |
![](/images/extra/90/e2008091859496.jpg)
|
Closest focusing distance
|
![](/images/extra/90/e2008091859496.jpg)
|
0.21 m |
![](/images/extra/90/e2008091859496.jpg)
|
Maximum reproduction ratio
|
![](/images/extra/90/e2008091859496.jpg)
|
0.37x |
![](/images/extra/90/e2008091859496.jpg)
|
Zoom control
|
![](/images/extra/90/e2008091859496.jpg)
|
NA |
![](/images/extra/90/e2008091859496.jpg)
|
Macro focusing
|
![](/images/extra/90/e2008091859496.jpg)
|
NA |
![](/images/extra/90/e2008091859496.jpg)
|
Focus-limit switch
|
![](/images/extra/90/e2008091859496.jpg)
|
NA |
![](/images/extra/90/e2008091859496.jpg)
|
M/A mode
|
![](/images/extra/90/e2008091859496.jpg)
|
NA |
![](/images/extra/90/e2008091859496.jpg)
|
A-M mode switch
|
![](/images/extra/90/e2008091859496.jpg)
|
NA |
![](/images/extra/90/e2008091859496.jpg)
|
Focus lock button
|
![](/images/extra/90/e2008091859496.jpg)
|
NA |
![](/images/extra/90/e2008091859496.jpg)
|
Wight (approx.)
|
![](/images/extra/90/e2008091859496.jpg)
|
730 g |
![](/images/extra/90/e2008091859496.jpg)
|
Dimensions (approx.) (from the cameras lens mounting flange)
|
![](/images/extra/90/e2008091859496.jpg)
|
82.5 x 108 mm |
![](/images/extra/90/e2008091859496.jpg)
|
Lens cap
|
![](/images/extra/90/e2008091859496.jpg)
|
Snap-on |
![](/images/extra/90/e2008091859496.jpg)
|
Lens hood
|
![](/images/extra/90/e2008091859496.jpg)
|
HB-41 |
![](/images/extra/90/e2008091859496.jpg)
|
Lens case
|
![](/images/extra/90/e2008091859496.jpg)
|
CL-1120 |
![](/images/extra/90/e2008091859496.jpg)
|
Tripod collar
|
![](/images/extra/90/e2008091859496.jpg)
|
NA |
![](/images/extra/90/e2008091859496.jpg)
|
External front filter attachment frame
|
![](/images/extra/90/e2008091859496.jpg)
|
Does not rotate |
![](/images/extra/90/e2008091859496.jpg)
|
External front filter
|
![](/images/extra/90/e2008091859496.jpg)
|
77 mm |
![](/images/extra/90/e2008091859496.jpg)
|
Slip-on filter
|
![](/images/extra/90/e2008091859496.jpg)
|
NA |
![](/images/extra/90/e2008091859496.jpg)
|
Built-in/rear filte
|
![](/images/extra/90/e2008091859496.jpg)
|
NA |
![](/images/extra/90/e2008091859496.jpg)
|
Circular polarizing filter II
|
![](/images/extra/90/e2008091859496.jpg)
|
NA |
![](/images/extra/90/e2008091859496.jpg)
|
Infrared compensation scale
|
![](/images/extra/90/e2008091859496.jpg)
|
NA |
![](/images/extra/90/e2008091859496.jpg)
|
Optional accessories
|
![](/images/extra/90/e2008091859496.jpg)
|
77 mm screw-in filters |
![](/images/extra/90/e2008091859496.jpg)
|
Aperture ring
|
![](/images/extra/90/e2008091859496.jpg)
|
Does have |
![](/images/extra/90/e2008091859496.jpg)
|
Distance scale
|
![](/images/extra/90/e2008091859496.jpg)
|
Does have |
![](/images/extra/90/e2008091859496.jpg)
|
Note: The Nikon D3 can be used without any limitation. With other cameras, there are limitations in tilt/shift operation. The Nikon F90X series, F90 series, F70, F60D, F55, F50D, F-401 series, F-801 series, F-601, F-601M, F3AF, F-501, PRONEA S or MF cameras cannot be used. |
