All stock codes associated to this product
GCS180201, GCS1802-01
2 Port KVMP Switch with USB 2.0 Hub and Audio
GCS1802
Description
The
GCS1802 is the latest addition to IOGEAR's market leading KVM product line. It is a 2-port KVMP switch with stereo audio ports and an integra
ted 2-port
USB 2.0 hub. Now users can control two computers and share multiple
USB peripherals from a single keyboard, monitor, and mouse console.
It features the paten
ted asynchronous switching, which allows the user to independently switch applications between the connec
ted computers. You can run an application on one computer while running another application on the other. Moreover, the integra
ted 2-port
USB 2.0 hub is available for each computer to share multiple peripherals connec
ted directly to the hub or via daisy chaining external powered
USB 2.0 hubs. Access to such peripherals is performed on a one-at-a-time basis. Additionally, IOGEAR's Display Emulation Technology* makes the switch intelligent to read and remember the monitor's optimal display parameters and refresh rate.Finally, the audio ports allow for connecting powered PC speakers for stereo sound and a single microphone for audio input/output to each computer.
Switching between computers can be done in three convenient ways: 1) push button port selection loca
ted on the unit's front panel, 2) an On Screen Display (OSD) selection panel, and 3) a "Hotkey" programmable combinations entered from the keyboard.
Setup is fast and easy; simply plug the cables into their appropriate ports. There is no software to configure or install. Also, the included
USB to PS/2 converter permits flexible configurations for the keyboard and mouse.
*IOGEARs Display Emulation Technology provides the EDID support for Windows 7
Features
- 2-port KVMP switch w/ built-in 2-port High Speed USB 2.0 hub
- Dual interface - Supports computers with PS/2 or USB keyboard and mouse configurations**
- Audio enabled - Full bass response provides 2.1 stereo sound
- Console audio ports on front panel for easy access
- Independent (Asynchronous) Hotkey switching between KVM focus, USB peripherals, and audio ports
- Three convenient computer switching methods - front panel pushbutton, On Screen Display (OSD), or Hotkeys
- Maximum VGA video resolution 2048 x 1536 - supports widescreen monitors
- IOGEAR's Display Emulation Technology reads and remembers the monitor's parameters (EDID) so the user doesn't experience delays or change in video resolution when switching between or booting computers*
- Console mouse port emulation bypass feature supports programmable mice
- Complete keyboard emulation for error free booting
- Sun/Mac keyboard support and emulation***
- Auto Scan Mode for sequentially monitoring all computers
- LED display for easy status monitoring
- Easy installation No software required
- Complete solution All cables included
*IOGEARs Display Emulation Technology provides the EDID support for Windows 7
**PS/2 KVM Cables are available and sold seperately.
*** PC keyboard combinations emulate Sun/Mac keyboards and Sun keyboards only work with Sun computers
Warranty: 3-YEAR
Function Diagram
Requirements
Console
Monitor with VGA capabilities
USB or PS/2 keyboard and mouse
Computers
VGA capable video out
USB or PS/2 connections
WindowsXP
Windows Vista (32-bit / 64-bit)
Windows 7*
Mac OSX or greater
Sun Solaris
Linux, UNIX and other USB supported systems**
Optional
Computers with sound support
2.0 or 2.1 powered PC speakers
Microphone
*IOGEAR’s Display Emulation Technology provides the EDID support for Windows 7
**Additional drivers and support may be needed
Package Content
1 x 2-Port USB KVMP Switch
2 x Custom USB KVM Cable
1 x PS/2 to USB Adapter
1 x Firmware Upgrade Cable
1 x Power Adapter
1 x Installation Guide
1 x Warranty Card
Specifications
UPC: 881317009500
| Function |
GCS1802 |
| CPU Connectors |
| Mouse |
USB or PS/2 |
| Keyboard |
USB or PS/2 |
| Monitor |
VGA |
| Microphone |
Standard |
| Audio |
2.1 sound |
| Peripherals |
2 ea USB 2.0 |
| Console Connectors |
| Mouse |
USB |
| Keyboard |
USB |
| Monitor |
VGA |
| Microphone |
Standard |
| Audio |
2.1 sound |
| Video Resolution |
2048 x 1536 [ DDC2B ] |
| Computer Connections |
| Direct |
2 |
| Cable Length |
6 ft [1.8 m] |
| Cable Connections |
| Input |
USB |
| Output |
USB or PS/2 |
| LEDs |
| USB Peripherals |
Green |
| Port ID |
Orange |
| Dimensions |
GCS1802 |
| Unit Dimensions |
| Width |
5.0 in [12.7 cm] |
| Height |
1.6 in [4.1 cm] |
| Depth |
2.9 in [7.4 cm] |
| Unit Package Dimensions |
| Width |
10.6 in [26.9 cm] |
| Height |
8.9 in [22.6 cm] |
| Depth |
4.0 in [10.2 cm] |
| Master Carton |
| Width |
18.2 in [46.2 cm] |
| Height |
11.3 in [28.7 cm] |
| Depth |
12.8 in [32.5 cm] |
| Master Carton Qty. |
6 ea |
| Weight |
| Master Carton Wt. |
23.0 lbs [10.4 kg] |
| Unit Pack Wt. |
3.6 lbs [1.6 kg] |
| Unit Wt. |
1.0 lb [.45 kg] |
