| General |
| Topology |
Line-Interactive High Frequency (Pure Sinewave, Booster + Fader) |
| Configuration |
Tower |
| Part Number |
5P650AU |
| Rating (VA/Watts) |
650/420 |
| Dimensions (H x W x D, mm) |
230 x 150 x 345 |
| Weight (kg) |
7.8 |
| Warranty |
3 years on electronics, 2 years on batteries |
Contents
(Ships with the following items) |
5P UPS
Eaton Intelligent Power Software CD
USB cable
Serial cable
Safety guide
Quick start guide
CD with 10-language user manual |
| |
| Electrical Input |
| Connection |
(1) Aust. 10A
|
| Input Voltage Without Using Batteries |
160V-294V (adjustable to 150V-294V) |
| Input frequency Range Without Using Batteries |
47 to 70Hz (50 Hz system), 56.5 to 70Hz (60 Hz system), 40Hz in low-sensitivity mode |
| |
| Electrical Output |
| Voltages |
230 V (+6/-10 %) (Adjustable to 200V / 220V / 230V / 240V) |
| Output Receptacles |
(3) IEC-320-C13
(2) Aust. 10A
|
| Remotely controlled sockets |
2 groups of 1 x AU (10 A) output receptacles |
| Output Frequency |
50/60 Hz +/- 0.1 % (autosensing) |
| |
| Battery |
Runtime
(minutes)
Load (watts)
Mouseover graph for detailed runtime values
50
100
150
200
250
300
350
400
0
5
10
15
20
25
30
35
40
45
50
Battery runtimes are approximate and may vary with equipment, configuration, battery age, temperature, etc.
|
| Battery Management |
ABM & temperature compensated charging method (user selectable), automatic battery test, deep discharge protection |
| Cold start (No mains power) |
Yes |
| |
| Communications |
| User Interface |
3 LEDS + Multilingual LCD : access to measures, alarm messages and customization |
| Communication Ports |
1 USB port + 1 RS232 serial port and relay contacts (USB and RS232 ports cannot be used simultaneously), 1 mini terminal block for remote ON/OFF and Remote Power Off |
| Communications Card Slots |
1 slot for Network-MS card, ModBus-MS or Relay-MS cards |
| |
| Environmental & Standards |
| Audible Noise |
< 40 dBA |
| Operating Temperature |
0 to 35C |
| Safety markings |
IEC/EN 62040-1 |
| EMC Markings |
IEC/EN 62040-2 class B (EMC), IEC/EN 62040-3 (performance), C-Tick |
| Approvals |
CE, CB report |
| Quality |
Designed, manufactured and marketed under ISO9001 & ISO14001 quality system |
