| General |
| Topology |
Line-Interactive High Frequency (Pure Sinewave, Booster + Fader) |
| Configuration |
Tower |
| Part Number |
5P1150AU |
| Rating (VA/Watts) |
1150/770 |
| Dimensions (H x W x D, mm) |
230 x 150 x 345 |
| Weight (kg) |
11.1 |
| Warranty |
3 years on electronics, 2 years on batteries |
Contents
(Ships with the following items) |
5P UPS
Eaton Intelligent Power Software CD
USB cable
Serial cable
Safety guide
Quick start guide
CD with 10-language user manual |
| |
| Electrical Input |
| Connection |
(1) Aust. 10A
|
| Input Voltage Without Using Batteries |
160V-294V (adjustable to 150V-294V) |
| Input frequency Range Without Using Batteries |
47 to 70Hz (50 Hz system), 56.5 to 70Hz (60 Hz system), 40Hz in low-sensitivity mode |
| |
| Electrical Output |
| Voltages |
230 V (+6/-10 %) (Adjustable to 200V / 220V / 230V / 240V) |
| Output Receptacles |
(3) IEC-320-C13
(2) Aust. 10A
|
| Remotely controlled sockets |
2 groups of 1 x AU (10 A) output receptacles |
| Output Frequency |
50/60 Hz +/- 0.1 % (autosensing) |
| |
| Battery |
Runtime
(minutes)
Load (watts)
Mouseover graph for detailed runtime values
100
200
300
400
500
600
700
Battery runtimes are approximate and may vary with equipment, configuration, battery age, temperature, etc.
|
| Battery Management |
ABM & temperature compensated charging method (user selectable), automatic battery test, deep discharge protection |
| Cold start (No mains power) |
Yes |
| |
| Communications |
| User Interface |
3 LEDS + Multilingual LCD : access to measures, alarm messages and customization |
| Communication Ports |
1 USB port + 1 RS232 serial port and relay contacts (USB and RS232 ports cannot be used simultaneously), 1 mini-terminal block for remote ON/OFF and Remote Power Off |
| Communications Card Slots |
1 slot for Network-MS card, ModBus-MS or Relay-MS cards |
| |
| Environmental & Standards |
| Audible Noise |
< 40 dBA |
| Operating Temperature |
0 to 35C |
| Safety markings |
IEC/EN 62040-1 |
| EMC Markings |
IEC/EN 62040-2 class B (EMC), IEC/EN 62040-3 (performance), C-Tick |
| Approvals |
CE, CB report |
| Quality |
Designed, manufactured and marketed under ISO9001 & ISO14001 quality system |
