| Panel |
Type |
IPS w/LED backlight |
Viewable Image Area
(diagonal) |
68,5 cm, (27 in.) widescreen; diagonally measured |
| Active Area (W x H) |
59,8 x 33,6 cm, (23.5 x 13.3 in.) |
| Aspect Ratio |
16:9 |
| Viewing Angle (typical)* |
Up to 178 horizontal/178 vertical (10:1 minimum contrast ratio) |
| Brightness (typical)* |
250 cd/m2 |
| Static Contrast Ratio (typical)* |
1000:1 |
| Dynamic Contrast Ratio (typical)* |
5,000,000:1 |
| Response Time (typical)* |
7ms w/overdrive (gray to gray) |
| Pixel Pitch |
0.3114 mm |
Backlight Lamp Life
(to half brightness)* |
30,000 hours minimum |
| Color Gamut (typical)* |
72% |
| Color Support** |
Can display up to 16.7 million colors |
*All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower.
** With the use of FRC technology. |
On Screen Display
(OSD) Controls |
Buttons or Switches |
Menu, Minus ("-"), Plus ("+") /Input Control, OK/Auto, Power |
| Languages |
10 (English, Spanish, German, French, Italian, Netherlands, Portuguese, Japanese, T-Chinese and S-Chinese) |
| User Controls |
Brightness, Contrast, Color, Image Control, OSD control, Management, Language, Information, Factory Reset, Input Control |
| Signal Interface/ Performance |
Horizontal Frequency |
24 to 94 kHz |
| Vertical Frequency |
50 to 76 Hz |
| Native Resolution |
1920 x 1080 @ 60 Hz |
| Preset VESA Graphic Modes (non-interlaced) |
1680 x 1050 @ 60 Hz
1600 x 900 @ 60 Hz
1440 x 900 @ 60 Hz
1366 x 768 @ 60 Hz
1280 x 1024 @ 60 Hz
1280 x 800 @60 Hz
1280 x 720 @ 60 Hz
1024 x 768 @ 60 Hz
800 x 600 @ 60 Hz
720 x 400 @ 70 Hz
640 x 480 @ 60Hz |
| Maximum Pixel Clock Speed |
170 MHz |
| User Programmable Modes |
Yes (10) |
| Anti-Glare |
Yes |
| Default Color Temperature |
6500 K |
| Video/Other Inputs |
Plug and Play |
Yes |
| Input Connectors |
VGA (analog), DVI-D, DisplayPort 1.2 (HDCP support on DVI-D and DisplayPort) |
| USB |
Integrated USB 2.0 hub with (2) Downstream and (1) Upstream ports |
| USB Cable |
(1)USB cable, 2 m (6.5 ft) |
| Video Cables |
(1)VGA, (1)DisplayPort
APJ Specific: (1)VGA and (1)DVI-D cables are included. DisplayPort cable is only available on limited models and in limited countries.
|
| Video Cable Lengths |
VGA 1,8 m (5.9 ft); DisplayPort 2 m (6.5 ft)
APJ specific: DVI-D 2 m (6.5 ft) (see APJ specific note above) |
| Audio |
N/A |
| Audio Cable Length |
N/A |
| Power |
Power Supply |
Internal |
| Input Power |
100-240V at 50/60Hz |
| Typical Power Consumption |
35 W |
| Maximum |
40 W |
| Power Saving |
0.5 W |
| Power Cable Length |
1,9 m (6.2 ft.) |
| Mechanical |
Dimensions (W x D x H) |
Unpacked w/stand |
64,2 x 27,85 x 53,21 cm
(25.28 x 10.96 x 20.95 in) |
Unpacked w/o stand
(head only) |
64,2 x 5,22 x 38,73 cm
(25.28 x 2.06 x 15.25 in) |
| Packaged |
70,2 x 17,1 x 60 cm
(27.64 x 6.73 x 23.62 in) |
| Base area (footprint) |
27,85 x 13,07 cm
(10.96 x 5.14 in) |
| Weight |
Head Only |
4,9 kg (10.8 lb) |
| Unpacked |
7,7 kg (16.98 lb) |
| Packaged |
10 kg (22.04 lb) |
| |
Tilt Range |
-5 to +30 |
| Swivel Range |
Yes, 360 |
| Height Adjustable |
Yes, 150 mm |
| Pivot Rotation |
Yes, 90 |
| |
Base |
Attached |
| Environmental |
Temperature - Operating |
5 to 35 C (41 to 95 F) |
| Temperature - Non-operating |
-20 to 60 C (-4 to 140 F) |
| Humidity - Operating |
20% to 80% non-condensing |
| Humidity - Non-operating |
5% to 95%, 38.7 C max wet-bulb |
| Altitude - Operating |
0 to 5,000 m (16,404 ft) |
| Altitude - Non-operating |
0 to 12,192 m (0 to 40,000 ft) |
| White LED Backlight |
Yes |
| CCFL Panel |
No |
| Arsenic-Free Display Glass |
Yes |
| Low Halogen4 |
Yes |
| Mercury- Free Display Backlighting |
Yes |
| Environmental Data |
Eco-Label Certifications & Declarations |
This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks
- IT ECO declaration
- US ENERGY STAR
- TCO 06 and TCO Certified Edge
- EPEAT Gold where HP registers commercial display products. See https://www.epeat.net for registration status in your country US Federal Energy Management Program (FEMP)
|
