All stock codes associated to this product
AP9559, 1000238, 731304123521
|
Agility |
|
Rack-Mountable |
|
Includes horizontal,
vertical, and toolless-mount varieties. Puts power where it is needed most
- in the racks near the equipment. |
|
Single input power source |
|
Supply power from one
branch whip to multiple pieces of equipment, conveniently powering
rack-mount equipment. Saves time and money during installation by using
one branch whip and standard connections. |
|
Wide range of input and output connections |
|
Product family includes
a variety of input and output connections to distribute 120V, 208V, or
230V power to multiple outlets. Having a variety of inputs and outputs
allow users to adapt to varying power requirements. APC offers units that
bring up to 14.4kW using a single branch whip. |
|
Total Cost of
Ownership |
|
Low Cost Power Distribution |
|
Provides a number of
outlets to bring power to rack equipment at an affordable
price. |
|
Marketing
Features |
|
Rack-Mountable |
|
Includes horizontal,
vertical, and toolless-mount varieties. Puts power where it is needed most
- in the racks near the equipment. |
|
Specification
|
Output |
|
Nominal Output Voltage |
|
208V ,
230V |
|
Maximum Total Current Draw |
|
16 |
|
Output Connections |
|
(12) IEC 320 C13
(Battery Backup) |
|
Input |
|
Nominal Input Voltage |
|
200V , 208V ,
230V |
|
Input frequency |
|
50/60
Hz |
|
Input Connections |
|
IEC-320
C20 |
|
Cord Length |
|
2.5
meters |
|
Number of Power Cords |
|
1 |
|
Load Capacity |
|
3680
VA |
|
Maximum Input Current |
|
16
A |
|
Physical |
|
Maximum Height |
|
44 mm , 4.4
cm |
|
Maximum Width |
|
447 mm , 44.7
cm |
|
Maximum Depth |
|
57 mm , 5.7
cm |
|
Rack Height |
|
1
U |
|
Net Weight |
|
2.05
kg |
|
Shipping weight |
|
3.64
kg |
|
Shipping Height |
|
70 mm , 7.0
cm |
|
Shipping Width |
|
464 mm , 46.4
cm |
|
Shipping Depth |
|
229 mm , 22.9
cm |
|
Color |
|
Black |
|
Environmental |
|
Operating Environment |
|
0 - 45
C |
|
Operating Relative Humidity |
|
0 - 95
% |
|
Operating Elevation |
|
0-3000
meters |
|
Storage Temperature |
|
-25 - 65
C |
|
Storage Relative Humidity |
|
0 - 95
% |
|
Storage Elevation |
|
0-15000
meters |
|
Conformance |
|
Approvals |
|
cUL Listed, CE,
Queensland Australia, UL 60950, UL Listed, VDE |
|
Standard warranty |
|
2 years repair or
replace |
|
Sustainable Offer
Status |
|
RoHS |
|
Compliant |
|
PEP |
|
Available in
Documentation tab |
|
EOLI |
|
Available in
Documentation tab |
|
ts_other_compliance_info |
|
China
RoHS |
|
