All stock codes associated to this product
03GP46367KR, 03G-P4-6367-KR, 11EGTX10606367, 11E-GTX1060-6367
Overview
Details
Performance
Memory
Cooling
Interface
-
PCI-E
3.0 16x
-
DVI-D,
DisplayPort, DisplayPort, HDMI, DisplayPort
Resolution & Refresh
- Max Monitors Supported: 4
- 240Hz
Max Refresh Rate
- Max
Digital : 7680x4320
Dimensions
Operating System Support
-
Windows
10 32/64bit
-
Windows
8 32/64bit
-
Windows
7 32/64bit
Requirements
-
Minimum
of a 400 Watt power supply.
-
One
available 8-pin PCI-E power dongle
-
Total
Power Draw : 150 Watts
Product Warranty
This product comes with a 3 year warranty. Registration is recommended.
Features
NVIDIA GameStream Technology
Stream extreme GeForce GTX PC gaming experiences to portable device like
NVIDIA SHIELD with super-smooth, low-latency performance.
OpenGL 4.5 Support
Supporting the latest standards in the OpenGL API.
VR Ready
Discover next-generation VR performance, the lowest latency, and
plug-and-play compatibility with leading headsets-driven by NVIDIA VRWorks
technologies.
NVIDIA GPU Boost 3.0
Dynamically maximizes clock speeds based on workload and allows
enthusiast-class controls such as temperature target and fan controls, extra
over-voltage headroom, and optimizations for water-cooling solutions. This
allows gamers to push performance to new levels.
Vulkan API
A next generation graphics and compute API from Khronos Group that provides
high-efficiency, cross-platform access to modern GPUs.
Max Digital Resolution - 7680x4320
DisplayPort 1.4 Ready supporting up to 7680x4320 resolution at 60Hz
Built for EVGA Precision XOC
This new version of Precision is built for the NVIDIA Pascal architecture and
combines the best of EVGA Precision and EVGA OC Scanner to give you never before
seen overclocking features and built in automatic tuning.
NVIDIA G-SYNC Ready
NVIDIA G-SYNC monitors feature revolutionary NVIDIA technology that
eliminates screen tearing while also reducing input lag. The result is the
smoothest, fastest, and most responsive gaming experience ever seen.
Simultaneous Multi-Projection
Simulates seperate viewports of the same scene giving improved performance in
VR and improved display accuracy in NVIDIA Surround.
NVIDIA Ansel
Revolutionary new 360-degree image capture..
Microsoft DirectX 12
Support for the latest Microsoft DirectX API to enable next-generation
gaming.
PCI Express 3.0
This card is designed for the PCI Express 3.0 bus architecture, offering the
highest data transfer speeds for the most bandwidth-hungry games and 3D
applications. It also maintains backwards compatibility with existing PCI
Express motherboards for the broadest support.
HDMI 2.0b, DisplayPort 1.4 and Dual-Link DVI
The latest standards in DisplayPort and HDMI interfaces.
EVGA ACX 3.0 Cooling
EVGA ACX 3.0 once again brings new and exciting features to the award winning
EVGA ACX cooling technology. SHP 2.0 gives increased heatpipes and copper
contact area for cooler operation, and optimized fan curve for even quieter
gaming. Of course, ACX 3.0 coolers also feature optimized swept fan blades,
double ball bearings and an extreme low power motor, delivering more air flow
with less power, unlocking additional power for the GPU.
Specifications
|
Base / Boost
(Clock) |
1506 /
1708 |
|
BIOS
Chips |
1 |
|
Cooler
Type |
ACX
3.0 |
|
Power
Type |
8-Pin |
|
Power
Phase |
6+1 |
|
Max Power
Draw |
150W |
|
Performance
Level |
Good |
|
Backplate |
No |
