TECHNOLOGY |
Projection Technology |
Epson 3LCD, 3-chip technology |
LCD Panel |
0.67-inch panel |
|
OPTICAL |
Zoom Ratio |
1.0 - 1.6 (Optical Zoom) |
Screen Size (Projection Distance) |
50" to 300" [1.46 to 8.95m] (Zoom: Wide)
50" to 300" [2.43 to 14.79m] (Zoom: Tele) |
Projection Distance |
80" screen 2.36m - 3.92m |
Throw Ratio |
1.38 (Zoom: Wide), 2.28 (Zoom: Tele) |
Projection Lens F Number |
1.5 - 2.0 |
Projection Lens Focal Length |
23mm - 38.4mm |
Focus Method |
Manual Focus |
Offset |
10:-1 |
|
IMAGE |
White Light Output |
5,000 lumens |
Colour Light Output |
5,000 lumens |
Resolution |
WUXGA |
Native Aspect Ratio |
16:10 |
Contrast Ratio |
15,000:1 |
Keystone Correction |
Vertical: -30 to +30 degrees; Horizontal: -30 to +30 degrees |
|
CONNECTIVITY |
Input: Video |
1 x RCA (Yellow) |
Input: Computer |
2 x D-sub 15-Pin (RGB), 1 x USB 2.0 type B |
Input: USB Memory Device |
1 x USB Type A |
Input: Three-In-One USB Display |
1 x USB 2.0 Type B |
Input: Digital |
2 x HDMI (1 x MHL) |
Input: Audio |
1 x RCA (Red/White), 2 x Stereo mini jack |
Input: Control |
1 x USB 2.0 type B, 1 x RS232C |
Input : HDBaseT |
NA |
Input: Epson USB Document Camera |
1 x USB 2.0 type A |
Network I/O: |
1 x RJ45 (100Mbps) |
Wireless Connectivity |
included |
WiDI/Miracast |
NA |
Output: Video |
1 x D-sub 15 pin (black moulding) |
Output: Audio |
1 x Stereo mini jack |
Speaker Output |
16W |
|
ADVANCED FEATURES |
EasyMP Network &Control |
Yes |
EasyMP Network Projection |
Yes |
PC Free Presentations |
Yes |
USB Plug 'n Play |
Yes |
AV Mute Slide |
Yes |
Instant Off |
Yes |
Auto Power On |
Yes |
Direct Power On/Off |
Yes |
Security |
* KensingtonĀ® - lock provision; * Padlock &Security cable hole; * Wireless LAN unit lock; * Password protect function |
Colour Modes |
Dynamic, Presentation, Cinema, sRGB, Blackboard, DICOM SIM |
|
GENERAL |
Dimensions (excl feet) DxWxH |
291 x 377 x 110mm |
Weight |
4.8kg |
Compatible lamp model |
ELPLP95 (New) |
Lamp Warranty |
1 Year (or 750 hours) * Whichever comes first. For more information visit Epson Projector Warranty |
Projector Warranty |
3 Years |
Power Consumption: Lamp On |
420W (Normal); 350W (ECO) |
Power Consumption: Standby |
0.5W (communication off) |
Noise Level |
Normal: 39dB;
ECO: 29dB |
