General |
|
|
Topology |
On-line double conversion with Power Factor Correction (PFC)
system |
|
Configuration |
Tower/Rack 3U |
|
Part Number |
9PX3000IRTM (The Marine Filter (9PXMF3KI) is required for IEC/EN 60945
compliance) |
|
Color |
metallic grey |
|
Rating (VA/Watts) |
3000/3000 |
|
Dimensions (H x W x D, mm) |
130 x 440 x 485 |
|
Weight (kg) |
27.4 |
|
Warranty |
3 years on electronics, 2 years on batteries |
|
Rail Kit Included |
Yes |
|
Efficiency |
up to 94% in online mode (up to 98% in Hi-efficiency
mode) |
|
|
|
Electrical Input |
|
|
Connection |
(1) IEC-320-C20 |
|
 |
|
Input Voltage Range |
176-276V without derating (up to 100-276V with
derating) |
|
Nominal Voltage |
200/208/220/230/240V |
|
Frequency Range |
40-70Hz, 50/60Hz autoselection, frequency converter
mode |
|
|
|
Electrical Output |
|
|
Nominal Voltage |
200/208/220/230/240V |
|
Outlets |
(8) IEC-320-C13 |
|
 |
|
(2) IEC-320-C19 |
|
 |
|
Battery |
|
|
Optional Extended Battery Module |
9PXEBM72RT3U |
|
Battery Management |
ABM & temperature compensated charging method (user selectable),
automatic battery test, deep discharge protection, automatic recognition
of external battery units |
|
|
|
Communications |
|
|
Communication Ports |
1 USB port + 1 serial RS232 port + 1 mini-terminal block for remote
ON/OFF + 1 mini-terminal block for remote power off + 1 mini-terminal
block for output relay |
|
Communication Slot |
1 slot for Network-MS card, ModBus-MS or Relay-MS
cards |
|
|
|
Environmental & Standards |
|
|
Audible Noise |
40 dB |
|
Operating Temperature |
0C to 40C |
|
Safety markings |
IEC/EN 62040-1, UL 1778, CSA 22.2 |
|
EMC Markings |
IEC/EN 62040 -2, FCC Class B, CISPR22 Class B |
|
Approvals |
DNV-GL Type approved /CE /CB report (TUV) / cULus / EAC /RCM / KC /
Energy Star |
