Aten EA1440 Photo
Door Sensor
For the security of your data center, ATEN provides Photo Door sensor probes
that work in tandem with the Power Distribution Units, which allows the
monitoring of a rack mounted enclosure´s door access, notifying users when a
door has been opened. Various conditions can be monitored with alarms according
to customizable minimum/maximum settings.
* The Sensor is an optional accessory and you can use the ATEN PDU without
the door sensors. However, if you want to have complete security management of
your data center with the full use of ATEN solutions, a sensor installation is
required.
Package Contents
- 1x Photo Door Sensor
- 1x Adjustment Tool
- 2x Screw
- 1x Bracket
- 1x Velcro
Features
- The Photo Door Sensor allows the monitoring of a rack mounted enclosure´s
door access - notifying users when a door has been opened
- High sensitivity
- Easy operation
Diagram
Specifications
|
Sensing distance |
10 cm |
|
|
|
|
Operating voltage |
10 - 30 VDC; Ripple<20% Peak to Peak |
|
|
|
|
Current Consumption |
30 mA(Max) |
|
|
|
|
Output method |
NPN &PNP Two Output |
|
|
|
|
Output status |
Normal open NO type |
|
|
|
|
Output current |
150 mA(Max) |
|
|
|
|
Leakage current |
0.8 mA(Max) |
|
|
|
|
Residual voltage |
0.6 mA(Max) |
|
|
|
|
Protection circuit |
Short Circuit &Polarity Protection |
|
|
|
|
Sensor Response Time |
1 ms(Max) |
|
|
|
|
Sensitivity adjuster |
270° Trimmer |
|
|
|
|
Hysteresis |
10% of Sensing Distance Max |
|
|
|
|
Emitter |
Infrared LED |
|
|
|
|
Illumination |
Sunlight < 10,000Lux.; Lamplight < 5,000Lux. |
|
|
|
|
Physical Properties |
|
|
|
|
|
Housing |
Plastic |
|
|
|
|
Note |
For some of rack mount products, please note that the standard physical
dimensions of WxDxH are expressed using a LxWxH
format. |
