Function |
VE811R |
VE811T |
|
Video Input |
|
|
|
Interfaces |
N/A |
1 x HDMI Type A Female (Black) |
|
Impedance |
N/A |
100 |
|
Max. Distance |
N/A |
1.8 m |
|
|
|
|
|
Video Output |
|
|
|
Interfaces |
1 x HDMI Type A Female (Black) |
N/A |
|
Impedance |
100 |
N/A |
|
|
|
|
|
Video |
|
|
|
Max. Data Rate |
10.2Gbps (3.4Gbps per lane) |
10.2Gbps (3.4Gbps per lane) |
|
Max. Pixel Clock |
340 MHz |
340 MHz |
|
Compliance |
HDMI (3D, Deep Color, 4K) |
HDMI (3D, Deep Color, 4K) |
|
|
HDCP Compatible |
HDCP Compatible |
|
|
Consumer Electronics Control (CEC) |
Consumer Electronics Control (CEC) |
|
Max. Resolutions / Distance |
Up to 4K@70m (Cat 5e/6) / 100m (Cat 6a/ATEN 2L-2910 Cat6); 1080p@100m
(Cat 5e/6/6a) |
Up to 4K@70m (Cat 5e/6) / 100m (Cat 6a/ATEN 2L-2910 Cat6); 1080p@100m
(Cat 5e/6/6a) |
|
|
*4K supported: |
*4K supported: |
|
|
4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0); |
4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0); |
|
|
4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4) |
4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4) |
|
|
|
|
|
Audio |
|
|
|
Input |
N/A |
1 x HDMI Type A Female (Black) |
|
Output |
1 x HDMI Type A Female (Black) |
N/A |
|
|
|
|
|
Connectors |
|
|
|
Unit To Unit |
1 x RJ-45 Female |
1 x RJ-45 Female |
|
Firmware Upgrade |
1 x Mini Stereo Jack Female (Black) |
1 x Mini Stereo Jack Female (Black) |
|
Power |
1 x DC Jack (Black) with locking |
1 x DC Jack (Black) with locking |
|
|
|
|
|
Switches |
|
|
|
Long Reach Mode Switch |
1 x Slide Switch - ON/OFF |
1 x Slide Switch - ON/OFF |
|
|
|
|
|
Power Consumption |
DC5V:3.77W:18 |
DC5V:3.84W:18 |
|
|
|
|
|
Environmental |
|
|
|
Operating Temperature |
0 - 40°C |
0 - 40°C |
|
Storage Temperature |
-20 - 60°C |
-20 - 60°C |
|
Humidity |
0 - 80% RH, Non-Condensing |
0 - 80% RH, Non-Condensing |
|
|
|
|
|
Physical Properties |
|
|
|
Housing |
Metal |
Metal |
|
Weight |
0.17 kg ( 0.37 lb ) |
0.16 kg ( 0.35 lb ) |
|
Dimensions (L x W x H) with bracket |
8.64 x 7.30 x 2.47 cm |
8.64 x 7.30 x 2.47 cm |
|
|
(3.4 x 2.87 x 0.97 in.) |
(3.4 x 2.87 x 0.97 in.) |
|
Dimensions (L x W x H) without bracket |
8.20 x 5.20 x 2.37 cm |
8.20 x 5.20 x 2.37 cm |
|
|
(3.23 x 2.05 x 0.93 in.) |
(3.23 x 2.05 x 0.93 in.) |
|
|
|
|
|
Note |
For some of rack mount products, please note that the standard physical
dimensions of WxDxH are expressed using a LxWxH format. |
|
