All stock codes associated to this product
PB750W, PB-750W, 4294629, 4710474946662
In-win PB-750W Premium Basic Series Power
Supply
Overview
CUSTOMIZE WITHOUT COMPROMISE
The all new PB Series is an 80 PLUS® gold certified gaming power supply.
Gamers can adjust the colors of the built-in RGB LED fan to match personal
preferences. Making a great lighting show for all your favorites!
Synchronization Lighting Effects
The PB Series is compatible with RGB-supported motherboards(4pin, 12V).
Simply activate the motherboard software and the power supply’s RGB LEDs will
perfectly complement your gaming rig.
RGB Mode
Gamers can also turn off the M/B RGB override button to manually switch the
colors or activate the breathing effect. It is available in eight colors: red,
green, dark blue, yellow, purple, light blue, white and breathing effect.
Completely match the theme of your rig!
The power supply also features a built-in memory function to save the applied
color, insuring the same selected color appears every time you boot your PC.
Hibernation Mode; Balancing Noise and Thermal Levels
The fluid dynamic bearing (FDB) 135mm fan will switch to hibernation mode
automatically once the system’s load is lower than 20%. This will maintain the
power supply’s stability and silence levels. The fan will begin to function when
the system’s load is over 20% and the lowest noise is only 18db.
Think Sync!
The PB Series is capable of synchronizing with other RGB sync-ready
components by using the 4-pin RGB headers (such as RGB fan, LED strip). Create
your own synchronized lighting show!
80 PLUS® Gold Certified Fully-Modular Power Supply
The PB Series delivers up to 90% efficiency, generating less heat and
effectively reducing operating cost.
5V and 3.3V DC to DC Design
DC to DC converter design provides superior dynamic response and supports a
foundation for greater system stability.
Highly Reliable Japanese Aluminium Electrolytic Capacitors
Premium Japanese capacitors with 105°C rating improve power stability at
higher temperatures and provides an ultra-long lifespan.
Fully Modular Cables for Quick and Easy Installation
The fully modular and low-profile cable design lets gamers quickly and easily
install without any difficulty.
CABLE INFORMATION
Specifications
|
Model |
PB-750W |
|
Part
Number |
IW-PB750-RGB |
|
Total
Power |
750W |
|
Material |
SECC |
|
Type |
ATX12V
V2.4 / EPS12V V2.92 |
|
Cable
Management |
Fully
Modular |
|
PFC |
Active
PFC ( >0.9) |
|
Efficiency |
80
PLUS Gold (Up to 90%) |
|
MTBF
(Hours) |
>100,000
hrs. |
|
AC
Input |
100
- 240Vac. 50-60Hz |
|
Fan |
135mm
FDB Fan |
|
|
(RGB
Lighting) |
|
Typical
Load Fan Noise(dBA) (50% Loading) |
<25dBA |
|
Operating
Temperature Range (°C) |
0~40
°C |
|
Full
Protection |
OCP
/ OVP / UVP / SCP / OTP / OPP |
|
Safety
Certifications |
cTUVus
/ TUV / CB / BSMI / CE / FCC / EAC / CCC / RCM |
|
Dimensions
(L x W x H) |
160
x 150 x 86mm |
|
Warranty |
5
Years |
|
Connector |
|
|
20+4
Pin Motherboard |
1 |
|
8
(4+4) Pin CPU |
2 |
|
8
(6+2) Pin PCI-E |
4 |
|
4
Pin Peripheral |
4 |
|
SATA
(90 Degree) |
12 |
|
Floppy |
1 |
|
RGB
LED Connector Modular Cable |
|
|
Lighting |
1 |
|
RGB
LED Controller |
1 |
