ATEN CL1000M-ATA-AU PS/2 VGA LCD Console

Aten CL1000M-ATA-AU PS/2 VGA LCD Console

Features

• Exclusive LED illumination light - designed by ATEN to illuminate the keyboard and touchpad to allow visibility in low-light conditions
• Integrated KVM console with 17" or 19â€� LED-backlit LCD monitor – in a sliding housing with top and bottom clearance for smooth operation in a 1U high system rack*
• LCD module rotates up to 115 degrees for a more comfortable viewing angle
• Slideawayâ„¢ housing is less than 1U – with top and bottom clearance for smooth operation in a 1U high system rack
• Compatible with most PS/2 KVM Switches
• Internal power supply
• Adjustable depth to fit within a rack

High video resolution:

• Supports input video resolutions up to 1920 x 1200 @ 60 Hz; and up to 1280 x 1024 @ 75 Hz with the built-in LCD screen

• Supports DDC, DDC2, DDC2B

• DDC emulation of the LCD monitor–Video settings of attached computers are automatically adjusted for optimal output to the LCD monitor

Keyboard Language support: English (US), English (UK), French, German, German (Swiss), Greek (CL1000N only), Hungarian, Italian, Japanese, Korean, Russian, Spanish, Swedish, and Traditional Chinese

Improved design – optional single person installation kit

Note: Custom KVM cables or converters are available for USB support

Compatible rack mounting kit:

1. CL1000M: 2X-010G, 2X-011G, 2X-012G
2. CL1000N: 2X-023G, 2X-024G, 2X-025G

Package Contents

• 1x CL1000M or CL1000N with Standard Rack Mount Kit
• 1x Custom KVM Cable (VGA, USB; 1.8m/6ft)
• 1x Power Cord
• 1x User Instructions

Overview

The CL1000 is a LCD KVM console that serves as the front-end for standard KVM switches. The CL1000 features an integrated 17" or 19� LED-backlit LCD panel, full keyboard, and touchpad in a 1U, rack-mountable, Slideaway™ housing.

Users who already have a switch can take advantage of the space saving and efficiency benefits of the CL1000 LCD KVM console without the unnecessary expense of having to purchase a KVM switch. This model provides convenient ‘at the rack’ console access to KVM switches already installed at your site.

Diagram

Specifications
